Tractor · 1994Unverified
New Holland 6610S
New Holland 6610S — 10S Series · 76 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
76 hp
Weight
5695 to 6335 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Utility tractorReference
Built in Queretaro, MexicoReference
Original price was $28,500 in 2000Reference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Engine
Ford 5.0L 4-cyl dieselReference
Engine63.4 kWReference
FordReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement5.0 LReference
Bore/Stroke112 x 127 mmReference
Power63.4 kWReference
Compression17.5:1Reference
Rated RPM2200Reference
Firing order1-3-4-2Reference
Starter volts12Reference
Oil capacity11.4 LReference
Coolant capacity13.0 LReference
Intake valve clearance0.406 mmReference
Exhaust valve clearance0.483 mmReference
Transmission
8-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears8 forward and 2 reverseReference
Four gears, plus reverse, in two ranges. Tractor must be stopped, and clutch used, before shifting gear or range.Reference
PTO & Hydraulics
PTO (claimed)56.7 kWReference
Typegear pumpReference
Pressure172.4 barReference
Valves2Reference
Pump flow36.7 lpmReference
Steering flow36.3 lpmReference
Steering cap.2.2 LReference
Rear TypeIIReference
Controlposition control with top-link draft sensingReference
Rear lift1832 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Engine RPM540@1900Reference
Capacities
Fuel81.4 LReference
Fuel50.0 LReference
Steering2.2 LReference
Dimensions
2WD Wheelbase222 cmReference
4WD Wheelbase225 cmReference
Weight5695 to 6335 poundsReference
Front tire7.50-16Reference
Rear tire16.9-30Reference
Ag front7.50-16 (2WD)Reference
Ag front14.9x24 (4WD)Reference
Ag rear16.9-30Reference
2WD Length368 cmReference
4WD Length388 cmReference
Height (ROPS)243 cmReference
2WD Weight2583 kgReference
4WD Weight2873 kgReference
2WD Ground clearance46 cmReference
4WD Ground clearance45 cmReference
6610S Serial Numbers
Location:Serial number decal inside the hood panel.Reference
1994ZX35000Reference
1995351863MReference
1996353483MReference
1997354758MReference
1998358416MReference
1999361105MReference
2000363210MReference
2001365619MReference
2002368034MReference
2003371020MReference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Charging volts12Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
