Tractor · 1996Unverified
New Holland 6635
New Holland 6635 — 35 Series · 76 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
76 hp
Weight
6834 to 7936 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Utility tractorReference
Built in ItalyReference
Original price was $33,250 in 1999Reference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post foldable ROPS. Cab optional with air-conditioning.Reference
Engine
Iveco 3.9L 4-cyl dieselReference
Fuel tank109.8 LReference
Engine63.4 kWReference
Iveco 8045.25Reference
turbocharged dieselReference
4-cylinder 8-valveReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke104 x 115 mmReference
Power63.4 kWReference
Pre-heatingThermostartReference
Rated RPM2500Reference
Starter volts12Reference
Oil capacity11.7 LReference
Coolant capacity14.0 LReference
Coolant capacity16.0 LReference
Transmission
12-speed partiallly synchronized with sync shuttleReference
24-speed partial power shiftReference
TransmissionSynchro CommandReference
Typepartiallly synchronized with sync shuttleReference
Gears12 forward and reverseReference
Four gears in three ranges with left-hand reverser. Gear and shuttle shifts are synchronized.Reference
TransmissionDual CommandReference
Typepartial power shiftReference
Gears24 forward and 12 reverseReference
Four gears in three ranges with two-speed power shift and left-hand reverser. The Dual Command provides push-button shifting to lower gear at each speed.Reference
PTO & Hydraulics
PTO (claimed)56.7 kWReference
Typeopen centerReference
Valves2 to 3Reference
Pump flow54.9 lpmReference
Rear TypeIIReference
Controlmechanical, lower linkReference
Rear lift (at 24"/610mm)2595 kgReference
Rear lift (at 24"/610mm)2875 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000Reference
Dimensions
2WD Wheelbase234 cmReference
4WD Wheelbase231 cmReference
Weight6834 to 7936 poundsReference
Front tire7.50-16Reference
Rear tire13.6-38Reference
Ag front7.50-16Reference
Ag rear13.6-38Reference
Width184 cmReference
Front tread142 to 213 cmReference
Rear tread152 to 213 cmReference
2WD ROPS Shipping3099 kgReference
2WD Cab Shipping3299 kgReference
4WD ROPS Shipping3400 kgReference
4WD Cab Shipping3599 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
ROPS Charging amps45Reference
Cab Charging amps65Reference
Battery volts12Reference
New Holland 6635 Height
ROPS267 cmReference
ROPS213 cmReference
Cab247 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
