Tractor · 1996Unverified
New Holland 7635
New Holland 7635 — 35 Series · 86 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
86 hp
Weight
6834 to 7936 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Utility tractorReference
Built in ItalyReference
Original price was $36,400 in 1999Reference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post foldable ROPS. Cab optional with air-conditioning.Reference
Engine
Iveco 3.9L 4-cyl dieselReference
Fuel tank109.8 LReference
Engine70.8 kWReference
Iveco 8045.25Reference
turbocharged dieselReference
4-cylinder 8-valveReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke104 x 115 mmReference
Power70.8 kWReference
Pre-heatingThermostartReference
Rated RPM2500Reference
Starter volts12Reference
Oil capacity11.7 LReference
ROPS Coolant capacity14.0 LReference
Cab Coolant capacity16.0 LReference
Transmission
24-speed partial power shiftReference
TransmissionDual CommandReference
Typepartial power shiftReference
Gears24 forward and 12 reverseReference
Four gears in three ranges with two-speed power shift and left-hand reverser. The Dual Command provides push-button shifting to lower gear at each speed.Reference
PTO & Hydraulics
PTO (claimed)64.1 kWReference
Typeopen centerReference
Valves2 to 3Reference
Pump flow54.9 lpmReference
Rear TypeIIReference
Controlmechanical lower link draft sensingReference
Rear lift (at 24"/610mm)2916 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000Reference
Dimensions
2WD Wheelbase234 cmReference
4WD Wheelbase231 cmReference
Weight6834 to 7936 poundsReference
Front tire7.50-16Reference
Rear tire13.6-38Reference
Ag front7.50-16Reference
Ag rear13.6-38Reference
Width184 cmReference
Front tread142 to 213 cmReference
Rear tread152 to 213 cmReference
2WD ROPS Shipping3099 kgReference
2WD cab Shipping3392 kgReference
4WD ROPS Shipping3400 kgReference
4WD Cab Shipping3599 kgReference
7635 Serial Numbers
19961087929Reference
19971104920Reference
19981129213Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
ROPS Charging amps45Reference
Cab Charging amps65Reference
Battery volts12Reference
New Holland 7635 Height
ROPS267 cmReference
ROPS213 cmReference
Cab247 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
