Tractor · 1994Unverified
New Holland 7810S
New Holland 7810S — 10S Series · 90 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
90 hp
Weight
7721 to 8361 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Utility tractorReference
Built in Queretaro, MexicoReference
Original price$33,000 (1998)Reference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post ROPS.Reference
Engine
Ford 6.6L 6-cyl dieselReference
Fuel tank81.4 LReference
Fuel tank50.0 LReference
Engine74.6 kWReference
FordReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke112 x 112 mmReference
Power74.6 kWReference
Compression17.5:1Reference
Rated RPM2100Reference
Starter volts12Reference
Oil capacity20.8 LReference
Coolant capacity16.1 LReference
Transmission
8-speed unsynchronized gearReference
16-speed two-speed power shiftReference
Typeunsynchronized gearReference
Gears8 forward and 2 reverseReference
Four gears, plus reverse, in two ranges. Tractor must be stopped, and clutch used, before shifting gear or range.Reference
TransmissionDual PowerReference
Typetwo-speed power shiftReference
Gears16 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)67.1 kWReference
Typegear pumpReference
Pressure172.4 barReference
Valves2Reference
Pump flow36.7 lpmReference
Rear TypeIIReference
Rear lift1832 kgReference
Rear PTOindependentReference
Rear PTO Type540/100Reference
Dimensions
2WD Wheelbase248 cmReference
4WD Wheelbase251 cmReference
Weight7721 to 8361 poundsReference
Front tire10.00-16Reference
Rear tire18.4-34Reference
Ag front10.00-16Reference
Ag rear18.4-34Reference
2WD Length394 cmReference
4WD Length415 cmReference
Height (ROPS)243 cmReference
2WD Weight3502 kgReference
4WD Weight3792 kgReference
2WD Ground clearance46 cmReference
4WD Ground clearance45 cmReference
7810S Serial Numbers
Location:Right-front upper portion of transmissionReference
1994ZX200000Reference
1995200000MReference
1996200642MReference
1997200933MReference
1998201465MReference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
