Tractor · 2001Unverified

New Holland 8870A

Name: New Holland 8870A
Brand: New Holland

New Holland 8870A — 70A Series · 180 hp. Reference specifications; pending source verification.

The New Holland 8870A is a tractor with a rated power of 180 hp, placing it at the higher power end of its class. This model was manufactured from 2001 to 2003, and is equipped with a 6-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. It has an operating weight of 17250 to 19590 pounds, and is suited to operations of 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

180 hp

Weight

17250 to 19590 pounds

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

180 hp

Transmissions

16-speed full power shift

Production years

2001-2003

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Row-Crop tractorReference

Two- or four-wheel driveReference

Differential lockelectro-hydraulicReference

Power steeringReference

Cab standard with air-conditioning.Reference

Engine

New Holland 7.5L 6-cyl dieselReference

New HollandReference

turbocharged intercooled dieselReference

6-cylinderReference

liquid-cooledReference

Displacement7.5 LReference

Bore/Stroke112 x 127 mmReference

Compression17.5:1Reference

Rated RPM2100Reference

StarterelectricReference

Starter volts12Reference

Oil capacity21.3 LReference

Coolant capacity26.5 LReference

Transmission

16-speed full power shiftReference

Typefull power shiftReference

Gears16 forward and 9 reverseReference

PTO & Hydraulics

PTO (claimed)134.2 kWReference

Hydraulic system140.0 LReference

Typeclosed center load-sensingReference

Capacity140.0 LReference

Pressure206.8 barReference

Valves3 or 4Reference

Pump flow117.3 lpmReference

Pump flow208.2 lpmReference

Rear TypeIIIReference

Controlelectronic draft sensingReference

Rear lift6718 kgReference

Rear PTOindependentReference

Clutchwet discReference

Rear PTO Type1000Reference

Capacities

Fuel416.4 LReference

Dimensions

2WD Wheelbase300 cmReference

4WD Wheelbase300 cmReference

SuperSteer Wheelbase311 cmReference

Weight17250 to 19590 poundsReference

Length538 cmReference

Height (cab)309 cmReference

Height (exhaust)314 cmReference

Ground clearance47 cmReference

Bar rear axle104 by 2844 mmReference

Bar rear axle104 by 3048 mmReference

2WD Front tread154 to 226 cmReference

4WD Front tread152 to 226 cmReference

SuperSteer Front tread152 to 223 cmReference

2WD Shipping7824 kgReference

4WD Shipping8477 kgReference

SuperSteer Shipping8886 kgReference

New Holland 8870A attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps130Reference

Batteries2Reference

Battery CCA850Reference

Battery volts12Reference

Speeds

With 18.4-42 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
