Tractor · 2000Unverified
New Holland 9184
New Holland 9184 — 84 Series · 240 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
240 hp
Max power
174.2 kW
Weight
17122 to 24970 pounds
Hover a source tag to verify
Overview
DistributorNew HollandReference
ManufacturerVersatileReference
Four-wheel Drive (4WD) tractorReference
Built in Winnipeg, Manitoba, CanadaReference
Four-wheel driveReference
Final drivesplanetaryReference
Articulated power steeringReference
Hydraulic disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Cummins 8.3L 6-cyl dieselReference
Engine (gross)179.0 kWReference
Drawbar (tested)149.6 kWReference
Cummins C8.3Reference
turbocharged aftercooled dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement8.3 LReference
Bore/Stroke114 x 135 mmReference
Power (gross)179.0 kWReference
Air cleanerdual paper elementsReference
Compression16.5:1Reference
Rated RPM2100Reference
Idle RPM950-2500Reference
Torque1118.7 NmReference
Torque RPM1500Reference
Firing order1-5-3-6-2-4Reference
Starter volts12Reference
Oil capacity21.7 LReference
Coolant capacity52.1 LReference
Max power174.2 kWReference
Power at rated engine speed157.9 kWReference
Max power149.6 kWReference
Transmission
12-speed partially synchronizedReference
TransmissionQuadrasyncReference
Typepartially synchronizedReference
Gears12 forward and 4 reverseReference
Clutchhydraulic wet discReference
Four synchronized gears in three ranges, plus reverse range. Gears may be shifted on the move, using the clutch. Tractor must be stopped, and clutch used, to shift range.Reference
PTO & Hydraulics
PTO (tested)174.2 kWReference
Hydraulic system75.7 LReference
Hydraulic system124.9 LReference
Typeclosed centerReference
Capacity75.7 LReference
Capacity124.9 LReference
Pressure155.1 barReference
Valves4Reference
Pump flow170.3 lpmReference
Steering flow102.2 lpmReference
Steering press.172.4 barReference
Rear TypeIVN/IIIReference
Rear lift (at 24"/610mm)5896 kgReference
DrawbarCat. 4Reference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type1000 (1.75)Reference
Engine RPM1000@2100Reference
Power at rated PTO speed170.8 kWReference
Capacities
Fuel870.6 LReference
Max capacity13154 kgReference
Dimensions
Wheelbase337 cmReference
Weight17122 to 24970 poundsReference
Front tire18.4-38Reference
Rear tire18.4-38Reference
Ag front18.4-38Reference
Ag rear18.4-38Reference
Length675 cmReference
Width367 cmReference
Height (cab)341 cmReference
Height (exhaust)366 cmReference
Shipping7766 kgReference
Operating11326 kgReference
9184 Serial Numbers
Location:Serial number plate mounted on the tractor cab's left, rear, corner.Reference
2001D108097Reference
2002D108515Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps130Reference
Batteries3Reference
Battery CCA625Reference
Battery volts12Reference
Test results
Diesel 12-speed 4WDJanuary 1 - September 1, 1999Link: OCED Tractor Test 1885 fileReference
PTO performanceReference
Fuel use55.6 l/hourReference
Fuel use55.3 l/hourReference
Fuel use57.2 l/hourReference
Drawbar performanceReference
Max pull11349 kgReference
Speeds
With 18.4-38 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
