Tractor · 1996Unverified
New Holland 9682
New Holland 9682 — Four-wheel Drive (4WD) tractor · 320 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
320 hp
Max power
251.7 kW
Weight
19730 to 31865 pounds
Hover a source tag to verify
Overview
DistributorNew HollandReference
ManufacturerVersatileReference
Four-wheel Drive (4WD) tractorReference
Built in Winnipeg, Manitoba, CanadaReference
Four-wheel driveReference
Steeringhydrostaic powerReference
Hydraulic dry disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Cummins 14.0L 6-cyl dieselReference
Engine268.5 kWReference
Drawbar (claimed)212.5 kWReference
Drawbar (tested)225.9 kWReference
Cummins N14Reference
turbocharged aftercooled dieselReference
6-cylinderReference
liquid-cooled verticalReference
Displacement14.0 LReference
Bore/Stroke140 x 152 mmReference
Power268.5 kWReference
Air cleanerdual paper elementsReference
Compression18.5:1Reference
Rated RPM2100Reference
Idle RPM900-2400Reference
Torque1647.5 NmReference
Torque RPM1400Reference
Firing order1-5-3-6-2-4Reference
Starter volts12Reference
Coolant capacity59.1 LReference
Oil capacity38.6 LReference
Oil change250 hReference
Max power251.7 kWReference
Power at rated engine speed238.5 kWReference
Max power225.9 kWReference
Transmission
12-speed partially synchronizedReference
12-speed full power shiftReference
TransmissionQuadra-SyncReference
Typepartially synchronizedReference
Gears12 forward and 4 reverseReference
Clutch11-inch hydraulic wet discReference
Four speeds (1-4) in three ranges (L/M/H) plus reverse range. Speed changes are synchronized using the clutch. Tractor must be stopped to shift ranges. Depressing the clutch fully activates a transmission brake, it is recommended to depress it two-thirds when shifting gears.Reference
TransmissionPower ShiftReference
Typefull power shiftReference
Gears12 forward and 2 reverseReference
Clutch9-inch hydraulicReference
Power shift transmission operated with a single control lever. Lever is moved ahead for forward range and to the back for reverse range, the neutral-lock button must be pressed to move the lever into range. Pushing right up-shifts and left down-shifts. Transmission always begins in first gear. Pressing the clutch while in motion will cause the transmission to automatically down-shift to match ground speed.Reference
PTO & Hydraulics
PTO (claimed)238.6 kWReference
PTO (tested)251.7 kWReference
Hydraulic system117.3 LReference
Hydraulic system124.9 LReference
Typeclosed center load sensingReference
Capacity117.3 LReference
Capacity124.9 LReference
Pressure155.1 barReference
Valves1 to 4Reference
Pump flow189.2 lpmReference
SCV flow113.6 lpmReference
Steering flow113.6 lpmReference
Steering press.172.4 barReference
Rear TypeIVN/3 (optional)Reference
Rear lift (at 24"/610mm)5896 kgReference
Rear PTOindependent (optional)Reference
Clutchelectro-hydraulic wet discReference
Rear PTO Type1000 (1.75)Reference
Engine RPM1000@2100Reference
Capacities
Total Fuel927.3 LReference
Usable Fuel870.6 LReference
Front hubs7.6 LReference
Front hubs12.1 LReference
Front diff.26.9 LReference
Rear hubs7.6 LReference
Rear hubs12.1 LReference
Rear diff.26.9 LReference
Max capacity17236 kgReference
Dimensions
Wheelbase337 cmReference
Weight19730 to 31865 poundsReference
Front tire20.8R42Reference
Rear tire20.8R42Reference
Ag front20.8R42Reference
Ag rear20.8R42Reference
Length675 cmReference
Width381 cmReference
Height (cab)347 cmReference
Height (exhaust)372 cmReference
Shipping8949 kgReference
Operating14453 kgReference
9682 Serial Numbers
Location:Rear lower-left side of the tractor cab, just above platform.Reference
1996D103393Reference
1997D104389Reference
1998D106500Reference
1999D107868Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps130Reference
Charging volts12Reference
Batteries3Reference
Battery CCA950Reference
Battery volts12Reference
Battery GroupSAE31Reference
Test results
Diesel Quadra-Sync 4WDOctober 1998 - 1998, Link: OCED Tractor Test 1816 fileReference
PTO performanceReference
Fuel use68.1 l/hourReference
Fuel use71.2 l/hourReference
Drawbar performanceReference
Fuel use75.3 l/hourReference
Max pull15708 kgReference
Speeds
With 20.8R42 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
