New Holland Boomer 3040

Name: New Holland Boomer 3040
Brand: New Holland

New Holland Boomer 3040 — Model year 2008-20122013-2016 · 40 hp. Reference specifications; pending source verification.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

40 hp

Weight

3295 to 4026 pounds

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Compact Utility tractorReference

Original price was $20,359 in 2009Reference

Two- or four-wheel driveReference

Steeringhydrostatic powerReference

Mechanical wet disc brakesReference

ROPS. Canopy optional. SuperSuite cab optional with heat and air-conditioning.Reference

Engine

Shibaura 2.0L 4-cyl dieselReference

Fuel tank49.2 LReference

Engine (gross)29.8 kWReference

Shibaura N844Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.0 LReference

Bore/Stroke84 x 90 mmReference

EmissionsTier IIIReference

Power (gross)29.8 kWReference

Pre-heatingglow plugsReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Oil capacity6.1 LReference

Transmission

hydrostatic powershiftReference

12-speed gearReference

continuously variable transmissionReference

TransmissionDualPowerReference

Typehydrostatic powershiftReference

Gearsinfinite forward and reverse (2-range)Reference

TransmissionSynchronized Shuttle ShiftReference

TypegearReference

Gears12 forward and reverseReference

TransmissionEasyDrive CVTReference

Typecontinuously variable transmissionReference

Gearsinfinite forward and reverseReference

PTO & Hydraulics

Gear PTO (claimed)26.1 kWReference

Hydro PTO (claimed)24.8 kWReference

Typeopen centerReference

Pressure172.4 barReference

Pump flow37.1 lpmReference

Total flow56.4 lpmReference

Steering flow19.3 lpmReference

Rear TypeIReference

Rear lift (at ends)1485 kgReference

Rear lift (at 24"/610mm)1056 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Mid PTOindependent (optional)Reference

Mid PTO Type2,200Reference

Dimensions

Wheelbase186 cmReference

Wheelbase205 cmReference

Weight3295 to 4026 poundsReference

Front tire8.0x16Reference

Rear tire14.9x24Reference

Weight396 kgReference

Weight444 kgReference

Ag front8.0x16Reference

Ag rear14.9x24Reference

Length309 cmReference

Length328 cmReference

Width173 cmReference

Height (ROPS)247 cmReference

Height (cab)229 cmReference

Ground clearance35 cmReference

Ground clearance29 cmReference

Front tread117 cmReference

Rear tread120 to 171 cmReference

1494 kgReference

1576 kgReference

1826 kgReference

New Holland Boomer 3040 attachments

84" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps40Reference

Charging amps55 (cab)Reference

Battery CCA600Reference

Battery volts12Reference

Attachment overview

84" mid-mount mower deckReference

New Holland 250TL loaderReference

New Holland 260TL loaderReference

BackhoeReference

In addition to the 84-inch 914A mid-mounted finish mower, the Boomer 3040 is compatible with a variety of rear-mounted mowers including finish mowers up to 90-inch, flex-wing mowers up to 17-foot, and flail mowers up 60 inch, and rotary cutters up to 84 inches. Front-mounted attachments for the Boomer 3040 include the 72CBH and 84CBH blades, 72CSH snow blower, and models 60CO and 72CO rotary brooms.Reference

84" Mower deck

Typemid-mount New Holland 914A-84"Reference

Type4-bladeReference

Cutting width213 cmReference

Overall width221 cmReference

Cut height5 to 10 cmReference

New Holland 920GH Backhoe

Backhoe typeNew Holland 920GH BackhoeReference

Bucket width22 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width45 cmReference

Bucket width60 cmReference

Bucket width91 cmReference

2-Foot flat digging depth228 cmReference

Reach from pivot312 cmReference

Loading height177 cmReference

Bucket force1263 kgReference

Dipperstick force916 kgReference

New Holland 930GH Backhoe

Backhoe typeNew Holland 930GH BackhoeReference
