Tractor · 2008Unverified

New Holland Boomer 3045

Name: New Holland Boomer 3045
Brand: New Holland

New Holland Boomer 3045 — Model year 2008-20122013-2016 · 45 hp. Reference specifications; pending source verification.

The New Holland Boomer 3045 is a tractor model with a rated power of 45 hp, positioning it at the lighter end of its class. It was manufactured from 2008 to 2016. The tractor features a 4-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a continuously variable transmission. Its operating weight is listed as 3497 to 4115 pounds, with a capacity for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

45 hp

Max power

45 hp

Weight

3497 to 4115 pounds

Catalogue coverage

Variants represented

Richest spec table

150 rows

Recorded power

45 hp

Recorded weight

396 kg

Transmissions

hydrostatic powershift

Production years

2008-2016

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Compact Utility tractorReference

Original price was $21,992 in 2009Reference

Four-wheel driveReference

Steeringhydrostatic powerReference

Mechanical wet disc brakesReference

ROPS. Canopy optional. SuperSuite cab optional with heat and air-conditioning.Reference

Engine

Shibaura 2.2L 4-cyl dieselReference

Fuel tank49.2 LReference

Engine (gross)33.6 kWReference

Shibaura N844LReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.2 LReference

Bore/Stroke84 x 100 mmReference

EmissionsTier IIIReference

Power (gross)33.6 kWReference

Pre-heatingglow plugsReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Oil capacity6.1 LReference

Fuel TypeDieselReference

No of Cylinders4 cylinderReference

Rated engine speed2,600 RPMReference

Emissions complianceTier IIIReference

Bore and stroke3.31x3.54 inchesReference

Cooling systemliquid-cooledReference

Transmission

hydrostatic powershiftReference

12-speed gearReference

continuously variable transmissionReference

TransmissionDualPowerReference

Typehydrostatic powershiftReference

Gearsinfinite forward and reverse (2-range)Reference

TransmissionSynchronized Shuttle ShiftReference

TypegearReference

Gears12 forward and reverseReference

TransmissionEasyDrive CVTReference

Typecontinuously variable transmissionReference

Gearsinfinite forward and reverseReference

Transmission TypeCVTReference

Wheel Drive4WDReference

Rear Axle Drive Typeinboard planetaryReference

PTO & Hydraulics

Gear PTO (claimed)29.5 kWReference

Hydro PTO (claimed)28.2 kWReference

Typeopen centerReference

Pressure172.4 barReference

Pump flow37.1 lpmReference

Total flow56.4 lpmReference

Steering flow19.3 lpmReference

Rear TypeIReference

Rear lift (at ends)1485 kgReference

Rear lift (at 24"/610mm)1056 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Mid PTOindependent (optional)Reference

Mid PTO Type2,200Reference

Dimensions

Wheelbase186 cmReference

Wheelbase205 cmReference

Weight3497 to 4115 poundsReference

Front tire8.0x16Reference

Rear tire14.9x24Reference

Weight396 kgReference

Weight444 kgReference

Ag front8.0x16Reference

Ag rear14.9x24Reference

Length309 cmReference

Length328 cmReference

Width173 cmReference

Height (ROPS)247 cmReference

Height (cab)229 cmReference

Ground clearance35 cmReference

Ground clearance29 cmReference

Front tread117 cmReference

Rear tread120 to 171 cmReference

1586 kgReference

1617 kgReference

1866 kgReference

New Holland Boomer 3045 attachments

84" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps40Reference

Charging amps55 (cab)Reference

Battery CCA600Reference

Battery volts12Reference

Total cold cranking amps600 CCAReference

Attachment overview

84" mid-mount mower deckReference

New Holland 250TL loaderReference

New Holland 260TL loaderReference

BackhoeReference

In addition to the mid-mounted 914A finish mower, the New Holland Boomer 3045 is factory-matched to a variety of rear-mounted mowing attachments. Rear mowers include finish mowers up to 90-inch, flex-wing mowers up to 17-foot, and flail mowers up 60 inch, and rotary cutters up to 84 inches. Front-mounted attachments for the Boomer 3045 include the 72CBH and 84CBH blades, 72CSH snow blower, and models 60CO and 72CO rotary brooms. Other factory-match attachments include tillers up to 80 inches (105A) and blades (both regular and box) up to 84 inches.Reference

84" Mower deck

Typemid-mount New Holland 914A-84"Reference

Type4-bladeReference

Cutting width213 cmReference

Overall width221 cmReference

Cut height5 to 10 cmReference

New Holland 920GH Backhoe

Backhoe typeNew Holland 920GH BackhoeReference

Bucket width22 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width45 cmReference

Bucket width60 cmReference

Bucket width91 cmReference

2-Foot flat digging depth228 cmReference

Reach from pivot312 cmReference

Loading height177 cmReference

Bucket force1263 kgReference

Dipperstick force916 kgReference

New Holland 930GH Backhoe

Backhoe typeNew Holland 930GH BackhoeReference

Bucket width22 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width45 cmReference

Bucket width60 cmReference

Bucket width91 cmReference

2-Foot flat digging depth259 cmReference

Reach from pivot340 cmReference

Loading height203 cmReference

Bucket force1859 kgReference

Dipperstick force966 kgReference

General

Make & ModelNew HollandReference

SCV controlJoystickReference

Rear Axle TypeFlangeReference

Capacities

Capacity135.2 ciReference

Crankcase oil volume6.4 qtsReference

Power

Max Power45 hpReference

PTO

PTO Power36 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540Reference

Mid PTO RPM2,000 RPMReference

Steering & brakes

BrakesWet disc brakesReference

Steering typePower steeringReference

Hydraulics

Pump Rated Output (total)14.9 gpmReference

Hydraulics Typeopen centerReference

Maximum operating pressure2,500 psiReference

Steering & Implements flow5.4 gpm (9.8 gpm)Reference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch maximum lift capacity1,606.2 kgReference

Rear Hitch Sensing Typetop link draft sensingReference

Dimensions & weight

Height Over Cab229.4 cmReference

Overall Height247.4 cmReference

Overall Length328.7 cmReference

Overall weight1,972.7 kgReference

Wheels & tyres

Rear Wheel Type14.9x24Reference

Front Wheel Type8.0x16Reference

Front Wheel tread range117.9 cmReference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
