Tractor · 2017Unverified
New Holland Boomer 45
New Holland Boomer 45 — Boomer Series · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
3424 to 4194 pounds
Hover a source tag to verify
Overview
ManufacturerNew Holland (a part of CNH)Reference
Compact Utility tractorReference
Original price$26,980 (2017 shuttle ROPS)Reference
Original price$34,077 (2017 hydro cab)Reference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Variants
Farmall 45Csimilar CaseIH modelReference
MT347similar LS modelReference
Engine
LS Mtron 1.9L 3-cyl dieselReference
ROPS Fuel tank39.7 LReference
Cab Fuel tank46.9 LReference
Engine (gross)33.6 kWReference
LS Mtron L3C19-TReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.9 LReference
Bore/Stroke88 x 103 mmReference
EmissionsTier IVReference
Emission controlexhaust gas recirculation with diesel particulate filterReference
Power (gross)33.6 kWReference
Fuel systemelectronic common rail direct injectionReference
Rated RPM2600Reference
Firing order1-3-2Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed synchronized shuttleReference
hydrostaticReference
Gear ROPS1553 kgReference
Typesynchronized shuttleReference
Gears16 forward and reverseReference
Four gears in four ranges with mechanical shuttleReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Gear PTO (claimed)28.5 kWReference
Hydro PTO (claimed)26.8 kWReference
Typeopen centerReference
Valves1 or 2Reference
Pump flow31.0 lpmReference
Gear Steering flow15.9 lpmReference
Hydro Steering flow20.1 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1250 kgReference
Rear lift (at 24"/610mm)959 kgReference
Rear Armstelescoping draft linksReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase185 cmReference
Weight3424 to 4194 poundsReference
Front tire9.5x16Reference
Rear tire13.6-24Reference
Weight327 kgReference
Weight387 kgReference
Standard tires (ag)Front: 9.5x16. Rear: 13.6-24Reference
Lawn/turf front28x8.50-15Reference
Lawn/turf rear41x14.00-20Reference
Industrial front12-16.5Reference
Industrial rear17.5Lx24Reference
Length325 cmReference
Width175 cmReference
Height (ROPS)246 cmReference
Height (cab)238 cmReference
Flange rear axleReference
Hydro ROPS1583 kgReference
Hydro cab1902 kgReference
New Holland Boomer 45 attachments
72" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
ROPS Charging amps70Reference
Cab Charging amps85Reference
Battery volts12Reference
Attachment overview
72" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
BackhoeReference
72" Mower deck
Typemid-mount New Holland 372GMSReference
Type3-bladeReference
Cutting width182 cmReference
New Holland 925GHB Backhoe
Backhoe typeNew Holland 925GHB BackhoeReference
Transport height195 cmReference
Digging depth233 cmReference
Reach from pivot304 cmReference
Loading height177 cmReference
Bucket Rotation174°Reference
Swing Arc175°Reference
Bucket force1429 kgReference
Dipperstick force933 kgReference
New Holland 935GHB Backhoe
Backhoe typeNew Holland 935GHB BackhoeReference
Transport height223 cmReference
Digging depth254 cmReference
Reach from pivot330 cmReference
Loading height193 cmReference
Bucket Rotation180°Reference
Swing Arc175°Reference
Bucket force2032 kgReference
Dipperstick force1148 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
