Tractor · 2004Unverified

New Holland Boomer TZ22DA

Name: New Holland Boomer TZ22DA
Brand: New Holland

New Holland Boomer TZ22DA — Boomer TZ Series · 22 hp. Reference specifications; pending source verification.

The New Holland Boomer TZ22DA is a tractor model with a rated output of 22 hp, making it one of the more compact options in its class. It was manufactured from 2004 to 2008. The tractor is equipped with a 3-cylinder diesel liquid-cooled engine, which drives through four-wheel drive via a hydrostatic transmission. It has a listed weight of 598 kg and is suited to jobs covering approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

22 hp

Weight

598 kg

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

22 hp

Recorded weight

598 kg

Transmissions

hydrostatic

Production years

2004-2008

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew Holland (a part of CNH)Reference

Sub-Compact Utility tractorReference

The New Holland TZ18DA is similar to the Shibaura SX21.Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post fixed ROPS.Reference

Variants

Farmall DX22Esimilar New Holland modelReference

Engine

Shibaura 1.0L 3-cyl dieselReference

Fuel tank29.9 LReference

Engine (gross)16.4 kWReference

Shibaura S753Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.0 LReference

Bore/Stroke75 x 72 mmReference

Power (gross)16.4 kWReference

Pre-heatingglow plugsReference

Rated RPM3000Reference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

PTO & Hydraulics

PTO (claimed)12.7 kWReference

Typeopen centerReference

Pump flow14.2 lpmReference

Total flow21.2 lpmReference

Steering flow7.0 lpmReference

Rear TypeIReference

Rear lift (at 24"/610mm)317 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTOindependentReference

Mid PTO Type2200Reference

Dimensions

Weight598 kgReference

New Holland TZ22DA attachments

54" mid-mount mower deckReference

60" mid-mount mower deckReference

snowblowerReference

bladeReference

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps36Reference

Battery CCA325Reference

Battery volts12Reference

Attachment overview

54" mid-mount mower deckReference

60" mid-mount mower deckReference

SnowblowerReference

BladeReference

Front-end loaderReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
