Backhoe Loader · 1999Unverified
New Holland LB95
New Holland LB95 — LB Series · 92 hp. Reference specifications; pending source verification.
The New Holland LB95 is a backhoe loader model with a power rating of 92 hp, positioning it in the middle of its class. Manufactured between 1999 and 2003, it is equipped with a 4-cylinder diesel liquid-cooled engine that drives the four-wheel drive system via a 4-speed gearbox. The LB95 has a listed weight of 8359 kg and is designed for use on tracts of land ranging from 200 to 800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
92 hp
Weight
8359 kg
Catalogue coverage
Variants represented
2
Richest spec table
63 rows
Recorded power
92 hp
Recorded weight
8359 kg
Transmissions
4-speed power shuttle
Production years
1999-2003
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Backhoe loader tractorReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Four-post ROPS/FOPS. Cab optional with air-conditioning.Reference
Engine
New Holland 5.0L 4-cyl dieselReference
Engine (gross)68.6 kWReference
Engine70.8 kWReference
New Holland 450 NBReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement5.0 LReference
Bore/Stroke112 x 127 mmReference
Power70.8 kWReference
Power (gross)68.6 kWReference
Torque355.3 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Oil capacity16.0 LReference
Coolant capacity24.0 LReference
Transmission
4-speed power shuttleReference
Typepower shuttleReference
Gears4 forward and reverseReference
Oil capacity18.0 LReference
Fully-synchronized transmission with torque converter and power shuttle.Reference
Capacities
Fuel129.8 LReference
PTO & Hydraulics
Hydraulic system137.0 LReference
Typeload sensingReference
Capacity137.0 LReference
Pressure210.0 barReference
Pump flow151.0 lpmReference
Dimensions
Wheelbase217 cmReference
Weight8359 kgReference
Front tire12.5/80-18Reference
Rear tire18.4-26Reference
Industrial front12.5/80-18Reference
Industrial rear18.4-26Reference
Length568 cmReference
Width243 cmReference
Height (cab)288 cmReference
Height (backhoe)388 cmReference
Clearance (front axle)37 cmReference
Backhoe & Loader
Dig depth495 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps70Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
New Holland Backhoe
Backhoe typeNew Holland BackhoeReference
Transport height388 cmReference
Digging depth495 cmReference
Reach from pivot588 cmReference
Loading height394 cmReference
Bucket Rotation160°Reference
New Holland HED Backhoe
Backhoe typeNew Holland HED BackhoeReference
Digging depth (extended stick)611 cmReference
Reach from pivot (extended stick)694 cmReference
Loading height (extended stick)464 cmReference
Bucket Rotation204°Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
