Lawn Tractor · 1999Unverified
New Holland MC22
New Holland MC22 — MC Series · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
1550 to 1630 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Front-mount mowerReference
Drive4x2 2WDReference
Drive4x4 4WDReference
Differential lockmechanical frontReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Optional four-post canopy.Reference
Engine
22HP Shibaura 1004cc 3-cyl dieselReference
Fuel tank50.3 LReference
ShibauraReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement61.3 ciReference
Bore/Stroke77 x 72 mmReference
Power16.4 kWReference
Air cleanerdual dry elementReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
Typeopen centerReference
Valves1Reference
Pump flow7.2 lpmReference
Front PTOindependentReference
Front PTO Type2200Reference
Dimensions
Wheelbase124 cmReference
Weight1550 to 1630 poundsReference
Front tire23x10.50-12Reference
Rear tire20x8.00-10Reference
Lawn/turf front23x10.50-12Reference
Lawn/turf rear20x8.00-10Reference
Lawn/turf front24x13.00-12Reference
Length241 cmReference
Width121 cmReference
Height (ROPS)193 cmReference
Height (ROPS)122 cmReference
2WD Weight703 kgReference
4WD Weight739 kgReference
Front axleFlangeReference
Front tread93 cmReference
2WD to inches100 to 0 cm Rear tread39.39Reference
4WD Rear tread99 cmReference
New Holland MC22 attachments
60" front-mount mower deckReference
72" front-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Charging amps40Reference
Battery CCA490Reference
Battery volts12Reference
Attachment overview
60" front-mount mower deckReference
72" front-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
