Lawn Tractor · 1999Unverified

New Holland MC28

Name: New Holland MC28
Brand: New Holland

New Holland MC28 — MC Series · 28 hp. Reference specifications; pending source verification.

The New Holland MC28 is a lawn tractor model with a rating of approximately 28 hp, positioning it at the upper end of its class in terms of power. Manufactured between 1999 and 2008, this model features a 3-cylinder diesel liquid-cooled engine and four-wheel drive with a hydrostatic transmission. The operating weight of the New Holland MC28 is specified as between 1570 and 1650 pounds. It is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

28 hp

Weight

1570 to 1650 pounds

Catalogue coverage

Variants represented

Richest spec table

58 rows

Recorded power

28 hp

Recorded weight

712 kg

Transmissions

hydrostatic

Production years

1999-2008

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Front-mount mowerReference

Drive4x2 2WDReference

Drive4x4 4WDReference

Differential lockmechanical frontReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Optional four-post canopy.Reference

Engine

28HP Shibaura 1329cc 3-cyl dieselReference

Fuel tank50.3 LReference

ShibauraReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement81.1 ciReference

Bore/Stroke84 x 80 mmReference

Power20.9 kWReference

Air cleanerdual dry elementReference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

PTO & Hydraulics

Typeopen centerReference

Valves1Reference

Pump flow9.1 lpmReference

Front PTOindependentReference

Front PTO Type2200Reference

Dimensions

Wheelbase124 cmReference

Weight1570 to 1650 poundsReference

Front tire23x10.50-12Reference

Rear tire20x8.00-10Reference

Lawn/turf front23x10.50-12Reference

Lawn/turf rear20x8.00-10Reference

Lawn/turf front24x13.00-12Reference

Length241 cmReference

Width121 cmReference

Height (ROPS)193 cmReference

Height (ROPS)122 cmReference

Height (Folded ROPS)122 cmReference

2WD Weight712 kgReference

4WD Weight748 kgReference

Front axleFlangeReference

Front tread93 cmReference

New Holland MC28 attachments

60" front-mount mower deckReference

72" front-mount mower deckReference

84" front-mount mower deckReference

snowblowerReference

bladeReference

Electrical

GroundnegativeReference

Charging amps40Reference

Battery CCA490Reference

Battery volts12Reference

Attachment overview

60" front-mount mower deckReference

72" front-mount mower deckReference

84" front-mount mower deckReference

SnowblowerReference

BladeReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
