Tractor · 2018Unverified
New Holland PowerStar 75
New Holland PowerStar 75 — PowerStar Series · 74 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
74 hp
Weight
5027 to 6239 pounds
Hover a source tag to verify
Overview
ManufacturerNew Holland (a part of CNH)Reference
Utility tractorReference
Original price was $70,392 in 2020Reference
Drive4x2 2WD: 4x4 MFWD 4WDReference
Final drivesinboard planetaryReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional.Reference
Variants
Farmall 75Csimilar CaseIH modelReference
Engine
FPT 3.4L 4-cyl dieselReference
Engine (gross)55.2 kWReference
front-end loaderReference
2WD Standard tires (ag)Front: 7.50x16. Rear: 16.9R30Reference
4WD Standard tires (ag)Front: 11.2R24. Rear: 16.9R30Reference
2WD ROPS2280 kgReference
4WD ROPS2699 kgReference
2WD Cab2550 kgReference
4WD Cab2830 kgReference
FPT F5DReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke99 x 110 mmReference
EmissionsTier IVReference
Emission controlDOC and EGRReference
Power (gross)55.2 kWReference
Fuel systemelectronic high-pressure common rail direct injectionReference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed power shuttleReference
12-speed mechanical shuttleReference
20-speed creeperReference
Typepower shuttleReference
Gears12 forward and reverseReference
Four synchronized gears in three ranges with power shuttle.Reference
Typemechanical shuttleReference
TypecreeperReference
Gears20 forward and reverseReference
PTO & Hydraulics
PTO (claimed)48.5 kWReference
Typeopen centerReference
Valves1 to 3Reference
Pump flow47.3 lpmReference
Total flow83.3 lpmReference
Steering flow36.0 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)1661 kgReference
Rear PTO Type540Reference
Rear PTO Type540/540EReference
Dimensions
2WD Wheelbase217 cmReference
4WD Wheelbase213 cmReference
Weight5027 to 6239 poundsReference
Front tire7.50x16Reference
2WD Rear tire16.9R30Reference
2WD Length388 cmReference
4WD Length383 cmReference
Width192 cmReference
Height (ROPS)265 cmReference
Height (cab)248 cmReference
Flange rear axleReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps120Reference
Battery volts12Reference
Attachment overview
New Holland 655TL NSL loaderReference
New Holland 655TL MSL loaderReference
New Holland 710LU loaderReference
New Holland 715LU loaderReference
Speeds
With 18R34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
