Tractor · 2008Unverified
New Holland T1110
New Holland T1110 — T1000 Series · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
676 kg
Hover a source tag to verify
Overview
ManufacturerNew Holland (a part of CNH)Reference
Sub-Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Shibaura 1.1L 3-cyl dieselReference
Fuel tank26.9 LReference
Engine (gross)20.9 kWReference
Shibaura S773LReference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.1 LReference
Bore/Stroke77 x 81 mmReference
Power (gross)20.9 kWReference
Rated RPM3100Reference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Oil capacity13.1 LReference
PTO & Hydraulics
PTO (claimed)15.3 kWReference
Typeopen centerReference
Pump flow17.6 lpmReference
Total flow24.6 lpmReference
Steering flow7.0 lpmReference
Rear TypeIReference
Controlmechanical position controlReference
Rear lift (at 24"/610mm)453 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2200Reference
Dimensions
Wheelbase146 cmReference
Weight676 kgReference
Front tire20x10.00-10Reference
Rear tire29x12.5-15Reference
Ag front20x10.00-10Reference
Ag rear29x12.5-15Reference
Length250 cmReference
Width132 cmReference
Height (ROPS)193 cmReference
Shipping weight676 kgReference
Ground clearance19 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Charging volts12Reference
Battery volts12Reference
Speeds
With 29x12.50-15 R4 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
