Tractor · 2008Unverified
New Holland T2210
New Holland T2210 — T2200 Series · 31 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
31 hp
Weight
1181 kg
Hover a source tag to verify
Overview
ManufacturerNew Holland (a part of CNH)Reference
Compact Utility tractorReference
Four-wheel driveReference
SteeringpowerReference
SteeringSuperSteer (optional)Reference
Two-post folding ROPS.Reference
Engine
Shibaura 1.5L 3-cyl dieselReference
Fuel tank27.6 LReference
Engine (gross)23.1 kWReference
Shibaura N843Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke84 x 90 mmReference
Power (gross)23.1 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
9-speed gearReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
TypegearReference
Gears9 forward and 3 reverseReference
PTO & Hydraulics
PTO (claimed)19.8 kWReference
PTO (claimed)18.6 kWReference
Typeopen centerReference
Pump flow27.3 lpmReference
Total flow46.6 lpmReference
Steering flow19.3 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)741 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Mid PTO Type2000Reference
Dimensions
Wheelbase160 cmReference
Weight1181 kgReference
Length285 cmReference
Width156 cmReference
Height (ROPS)215 cmReference
Height (Folded ROPS)169 cmReference
Shipping weight1181 kgReference
Clearance (front axle)33 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
