Tractor · 2008Unverified
New Holland T4020
New Holland T4020 — T4000 Series · 64 hp. Reference specifications; pending source verification.
The New Holland T4020 is a tractor with a rated power output of 64 hp, positioning it at the lighter end of its class. It was manufactured between 2008 and 2011. The model is equipped with a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, and features four-wheel drive with a hydrostatic transmission. Its operating weight is listed as 5776 to 6768 pounds, with a maximum operational area of 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
64 hp
Max power
37.9 kW
Weight
5776 to 6768 pounds
Catalogue coverage
Variants represented
2
Richest spec table
135 rows
Recorded power
64 hp
Transmissions
12-speed mechanical shuttle
Production years
2008-2011
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerNew Holland (a part of CNH)Reference
Utility tractorReference
Built in Jesi, ItalyReference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Platform with ROPS. Cab on deluxe model with heat and air-conditioning.Reference
Variants
Farmall 65Csimilar CaseIH modelReference
Engine
FPT 3.2L 4-cyl dieselReference
Fuel tank81.8 LReference
Fuel tank74.9 LReference
Engine (gross)47.7 kWReference
Drawbar (tested)37.9 kWReference
FPT F5CReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement3.2 LReference
Bore/Stroke99 x 104 mmReference
EmissionsTier IIIReference
Power (gross)47.7 kWReference
Air cleanerdual dry elementReference
Pre-heatingthermostartReference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Power at rated engine speed43.8 kWReference
Max power37.9 kWReference
Max power37.2 kWReference
Fuel TypeDieselReference
No of Cylinders4 CylinderReference
Rated engine speed2,300 RPMReference
Cooling systemliquid-cooledReference
Transmission
12-speed mechanical shuttleReference
16-speed mechanical shuttleReference
16-speed power shuttleReference
TransmissionSynchro CommandReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Four speeds and three ranges. Synchronized shift between speeds.Reference
Gears16 forward and reverseReference
Typepower shuttleReference
Transmission TypeGearReference
Wheel Drive4WDReference
PTO & Hydraulics
PTO (claimed)37.3 kWReference
PTO (tested)43.8 kWReference
Typeopen centerReference
Pressure190.0 barReference
Valves1 to 5Reference
Pump flow48.4 lpmReference
Pump flow60.9 lpmReference
Steering flow28.0 lpmReference
Steering flow35.6 lpmReference
Rear TypeII/IReference
Rear lift (at 24"/610mm)1797 kgReference
Rear PTOindependentReference
Clutch280mm mechanical dry discReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2196Reference
Power at rated PTO speed43.4 kWReference
Power at rated PTO speed43.5 kWReference
Dimensions
Wheelbase203 cmReference
Wheelbase209 cmReference
Wheelbase211 cmReference
Wheelbase217 cmReference
Weight5776 to 6768 poundsReference
Front tire11.2R24Reference
Rear tire16.9R30Reference
Standard tires (ag)Front: 11.2R24. Rear: 16.9R30Reference
Lawn/turf front13.6-16.1Reference
Lawn/turf rear16.9-24Reference
Lawn/turf front12LL-16Reference
Lawn/turf rear22.5L-16.1Reference
Industrial front12.5/80-18Reference
Industrial rear16.9-24Reference
Length343 cmReference
Length349 cmReference
Height (Folded ROPS)197 cmReference
Height (cab)232 cmReference
Front tread123 to 194 cmReference
Rear tread123 to 194 cmReference
Shipping2619 kgReference
Shipping2869 kgReference
Shipping2820 kgReference
Shipping3069 kgReference
2WD Max front axle2100 kgReference
4WD Max front axle2499 kgReference
Max rear axle3700 kgReference
New Holland T4020 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps85Reference
Battery CCA730Reference
Battery volts12Reference
Total cold cranking amps730 CCAReference
Attachment overview
New Holland 810TL loaderReference
New Holland 820TL loaderReference
Test results
OECD 2466: diesel 12-speed 4WDReference
OECD 2465: diesel 16-speed 4WDReference
Diesel 12-speed 4WDJune 2008 - July 2008, Link: OCED Tractor Test 2466 fileReference
PTO performanceReference
Fuel use13.6 l/hourReference
Drawbar performanceReference
Fuel use13.2 l/hourReference
Gear 3M used for power test.Reference
Max pull2846 kgReference
Gear 1M used for pull test.Reference
Diesel 16-speed 4WDMay 2008 - July 2008, Link: OCED Tractor Test 2465 fileReference
Gear 3ML used for power test.Reference
Max pull3172 kgReference
Gear 1ML used for pull test.Reference
General
Make & ModelNew HollandReference
SCV controlJoystickReference
Rollover protective structurePlatform with ROPSReference
Country of manufacturerItalyReference
Capacities
Capacity195 ciReference
PTO
PTO Power50 hpReference
Rear PTO PowerAvailableReference
Rear PTO RPM540 RPMReference
Steering & brakes
Brakeshydraulic wet discReference
Steering typehydrostatic powerReference
Hydraulics
Hydraulics Typeopen centerReference
Maximum operating pressure2,755 psiReference
Remote Valves1 to 5 ValvesReference
Steering & Implements flow9.4 gpm (16.1 gpm)Reference
Rear Hitch category (SAE designation)Category II/IReference
Dimensions & weight
Height Over ROPS197.6 cmReference
Height Over Cab232.2 cmReference
Overall Length349.3 cmReference
Overall weight2,869.9 kgReference
Wheels & tyres
Rear wheel tread range48.5 to 76.7 inchesReference
Front Wheel tread range48.7 to 76.6 inchesReference
Operator station
Cab AvailabilityAvailableReference
Seat SuspensionTRUEReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
