Tractor · 2008Unverified

New Holland T4040

Name: New Holland T4040
Brand: New Holland

New Holland T4040 — T4000 Series · 84 hp. Reference specifications; pending source verification.

The New Holland T4040 is a tractor with a rated output of 84 hp, placing it in the middle of its class for power. It was manufactured from 2008 to 2011. The tractor features a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, driving four-wheel drive via a hydrostatic transmission. It has a listed weight of 5953 to 6944 pounds and is suitable for jobs of approximately up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

84 hp

Max power

47.1 kW

Weight

5953 to 6944 pounds

Catalogue coverage

Variants represented

Richest spec table

139 rows

Recorded power

84 hp

Transmissions

12-speed mechanical shuttle

Production years

2008-2011

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Utility tractorReference

Built in Jesi, ItalyReference

Two- or four-wheel driveReference

Differential lockmechanical rearReference

Steeringhydrostatic powerReference

Hydraulic wet disc brakesReference

Platform with ROPS. Cab on deluxe model with heat and air-conditioning.Reference

Variants

T4040conventional chassisReference

T4040Fnarrow chassisReference

T4040Vultra-narrow chassisReference

Farmall 85Csimilar CaseIH modelReference

Engine

FPT 4.5L 4-cyl dieselReference

Fuel tank81.8 LReference

Fuel tank87.8 LReference

Engine (gross)62.6 kWReference

Drawbar (tested)47.7 kWReference

FPT NEFReference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooled inlineReference

Displacement4.5 LReference

Bore/Stroke104 x 132 mmReference

EmissionsTier IIIReference

Power (gross)62.6 kWReference

Air cleanerdual dry elementReference

Pre-heatingthermostartReference

Rated RPM2300Reference

StarterelectricReference

Starter volts12Reference

Power at rated engine speed56.1 kWReference

Max power47.1 kWReference

Power at rated engine speed56.2 kWReference

Max power47.7 kWReference

Fuel TypedieselReference

No of Cylinders4 CylinderReference

Rated engine speed2,300 RPMReference

Cooling systemliquid-cooledReference

Transmission

12-speed mechanical shuttleReference

16-speed mechanical shuttleReference

16-speed power shuttleReference

TransmissionSynchro CommandReference

Typemechanical shuttleReference

Gears12 forward and reverseReference

Four speeds and three ranges. Synchronized shift between speeds.Reference

Gears16 forward and reverseReference

Typepower shuttleReference

Transmission TypeMechanical ShuttleReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)52.2 kWReference

PTO (tested)56.2 kWReference

Typeopen centerReference

Pressure190.0 barReference

Valves1 to 5Reference

Pump flow60.9 lpmReference

Steering flow35.6 lpmReference

Rear TypeII/IReference

Rear lift (at 24"/610mm)1797 kgReference

Rear PTOindependentReference

Clutch280mm mechanical dry discReference

Rear PTO Type540 (1.375)Reference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@2196Reference

Power at rated PTO speed55.6 kWReference

Power at rated PTO speed55.4 kWReference

Dimensions

Wheelbase212 cmReference

Wheelbase218 cmReference

Wheelbase220 cmReference

Wheelbase226 cmReference

Weight5953 to 6944 poundsReference

Front tire11.2R24Reference

Rear tire16.9R30Reference

Standard tires (ag)Front: 11.2R24. Rear: 16.9R30Reference

Lawn/turf front13.6-16.1Reference

Lawn/turf rear16.9-24Reference

Lawn/turf front12LL-16Reference

Lawn/turf rear22.5L-16.1Reference

Industrial front12.5/80-18Reference

Industrial rear16.9-24Reference

Length352 cmReference

Length357 cmReference

Height (Folded ROPS)197 cmReference

Height (cab)232 cmReference

Front tread123 to 194 cmReference

Rear tread123 to 194 cmReference

Shipping2700 kgReference

Shipping2949 kgReference

Shipping2899 kgReference

Shipping3149 kgReference

2WD Max front axle2100 kgReference

4WD Max front axle2499 kgReference

Max rear axle3700 kgReference

New Holland T4040 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps120Reference

Battery CCA800Reference

Battery volts12Reference

Total cold cranking amps800 CCAReference

Attachment overview

New Holland 810TL loaderReference

New Holland 820TL loaderReference

Test results

OECD 2477: diesel 12-speed 4WDReference

OECD 2476: diesel 16-speed 4WDReference

Diesel 12-speed 4WDJuly 2008 - September 2008, Link: OCED Tractor Test 2477 fileReference

PTO performanceReference

Fuel use17.8 l/hourReference

Fuel use17.0 l/hourReference

Drawbar performanceReference

Fuel use17.4 l/hourReference

Gear 3M used for power test.Reference

Max pull2896 kgReference

Gear 3L used for pull test.Reference

Diesel 16-speed 4WDJuly 2008 - September 2008, Link: OCED Tractor Test 2476 fileReference

Gear 3MH used for power test.Reference

Max pull3304 kgReference

Gear 1MH used for pull test.Reference

General

Make & ModelNew HollandReference

SCV controlJoystickReference

Rollover protective structurePlatform with ROPSReference

Country of manufacturerItalyReference

Capacities

Capacity274 ciReference

PTO

PTO Power70 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 RPMReference

Steering & brakes

Brakeshydraulic wet discReference

Steering typehydrostatic powerReference

Hydraulics

Hydraulics Typeopen centerReference

Maximum operating pressure2,755 psiReference

Remote Valves1 to 5 ValvesReference

Steering & Implements flow9.4 gpm (16.1 gpm)Reference

Rear Hitch category (SAE designation)Category II/IReference

Dimensions & weight

Height Over ROPS197.6 cmReference

Height Over Cab232.2 cmReference

Overall Length357.9 cmReference

Overall weight2,949.7 kgReference

Wheels & tyres

Rear wheel tread range48.5 to 76.7 inchesReference

Front Wheel tread range48.7 to 76.6 inchesReference

Operator station

Cab AvailabilityAvailableReference

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
