Tractor · 2012Unverified
New Holland T4.75
New Holland T4.75 — Model year 2012-20142015-2017 · 74 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
74 hp
Max power
51.0 kW
Weight
4960 to 6172 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Utility tractorReference
Two- or four-wheel driveReference
Differential lockmechanical differential lockReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Two-post folding ROPS. Optional cab with air-conditioning.Reference
Engine
FPT 3.2L 4-cyl dieselReference
Fuel tank90.1 LReference
Engine (gross)55.2 kWReference
FPT F5CReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.2 LReference
Bore/Stroke99 x 104 mmReference
EmissionsTier 3Reference
Power (gross)55.2 kWReference
Air cleanerdryReference
Pre-heatinggrid heaterReference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Max power51.0 kWReference
Power at rated engine speed50.6 kWReference
Transmission
8-speed partially synchronized mechanical shuttleReference
8-speed power shuttleReference
12-speed mechanical shuttleReference
12-speed power shuttleReference
Typepartially synchronized mechanical shuttleReference
Gears8 forward and reverseReference
Four gears in two ranges. Gear shifts and shuttle are synchronized with the clutch. Tractor must be stopped to shift ranges. Optional creeper provdes an additional four speeds.Reference
Typepower shuttleReference
Four gears in two ranges. Left-hand hydraulic power shuttle. Optional creeper provides an additional four speeds.Reference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Four gears in three ranges. Optional creeper provides an additional eight speeds.Reference
Four gears in three ranges. Optional creeper provdes an additional eight speeds.Reference
PTO & Hydraulics
PTO (claimed)48.5 kWReference
PTO (tested)51.0 kWReference
Typeopen centerReference
Rear valves1 or 2Reference
Mid valves0 or 2Reference
Pump flow47.3 lpmReference
Total flow74.9 lpmReference
Steering flow27.6 lpmReference
Steering flow36.0 lpmReference
Rear Type2/1Reference
Controlmechanical upper-link draft sensingReference
Rear lift (at 24"/610mm)1661 kgReference
Rear PTOindependentReference
Clutchmechanical dry disc, wet disc with power shuttleReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2160Reference
Engine RPM540E@1592Reference
Power at rated PTO speed50.9 kWReference
Dimensions
2WD Wheelbase211 cmReference
4WD Wheelbase210 cmReference
Weight4960 to 6172 poundsReference
Length379 cmReference
Height (ROPS)200 cmReference
Height (cab)248 cmReference
Flange rear axleReference
2WD Front tread152 to 202 cmReference
4WD Front tread154 to 194 cmReference
Rear tread132 to 193 cmReference
2WD ROPS2249 kgReference
4WD ROPS2669 kgReference
2WD cab2519 kgReference
4WD cab2799 kgReference
New Holland T4.75 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps120Reference
Battery CCA730 (ROPS)Reference
Battery CCA800 (cab)Reference
Battery volts12Reference
Test results
Diesel 12-speed 4WDMarch 12 - 14, 2013Link: Nebraska Tractor Test 2054 fileReference
PTO performanceReference
Fuel use15.9 l/hourReference
Fuel use17.0 l/hourReference
Fuel use16.3 l/hourReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
