Tractor · 2008Unverified

New Holland T5040

New Holland T5040 — T5000 Series · 85 hp. Reference specifications; pending source verification.

The New Holland T5040 is a tractor model with a rated power of 85 hp, a mid-range figure for its class. Production of the T5040 occurred between 2008 and 2013. It is equipped with a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with a mechanical front-wheel drive and hydrostatic transmission. The tractor is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
85 hp
Max power
54.6 kW

Catalogue coverage

Variants represented
2
Richest spec table
118 rows
Recorded power
85 hp
Transmissions
12-speed mechanical shuttle
Production years
2008-2013
Verified variants
0

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference
Utility tractorReference
Built in Jesi, ItalyReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Differential lockmechanical rear standardReference
Differential lockoptional electrohydraulic front and rearReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Flat deck platform with ROPS. Cab optional with heat and air-conditioning.Reference

Engine

New Holland 4.5L 4-cyl dieselReference
Fuel tank126.8 LReference
Engine (gross)63.4 kWReference
Drawbar (tested)45.6 kWReference
New HollandReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
EmissionsTier IIIReference
Power (gross)63.4 kWReference
Air cleanerdual dry elementReference
Pre-heatinggrid heaterReference
Rated RPM2300Reference
Starter volts12Reference
Max power54.6 kWReference
Power at rated engine speed50.9 kWReference
Max power45.6 kWReference
Fuel TypedieselReference
No of Cylinders4 cylinderReference
Rated engine speed2,300 RPMReference
Emissions complianceTier IIIReference
Cooling systemliquid-cooledReference

Transmission

12-speed mechanical shuttleReference
12-speed power shuttleReference
20-speed mechanical shuttleReference
24-speed power shuttleReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Typepower shuttleReference
Gears20 forward and 12 reverseReference
TransmissionDual CommandReference
Gears24 forward and reverseReference
Transmission TypePower ShuttleReference
Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)52.2 kWReference
PTO (tested)54.6 kWReference
Typeopen centerReference
Pressure198.0 barReference
Rear valves2 to 3 (open or closed center)Reference
Mid valves0 to 2Reference
Pump flow60.9 lpmReference
Steering flow39.4 lpmReference
Rear TypeIIReference
Controlmechanical lower-link draft sensingReference
Rear lift (at 24"/610mm)2483 kgReference
Rear lift (at 24"/610mm)3086 kgReference
Rear PTOindependentReference
ClutchmechanicalReference
Clutchelectrohydraulic optionalReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2199Reference
Engine RPM1000@2261Reference
Power at rated PTO speed528.7 kWReference

Dimensions

Wheelbase234 cmReference
2WD Length234 cmReference
4WD Length234 cmReference
Height (ROPS)276 cmReference
Height (cab)256 cmReference
Flange rear axle1770 mmReference
Front tread149 to 209 cmReference
Front tread175 to 215 cmReference
2WD Max front axle3499 kgReference
4WD Max front axle4499 kgReference
Max rear axle4599 kgReference

New Holland T5040 attachments

front-end loaderReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Charging amps120Reference
Battery CCA960Reference
Battery volts12Reference
Total cold cranking amps960 CCAReference

Attachment overview

New Holland 820 loaderReference
New Holland 830 loaderReference

Test results

Diesel 12-speed 2WDJanuary 2009 - March 2009, Link: OCED Tractor Test 2502 fileReference
PTO performanceReference
Fuel use16.7 l/hourReference
Fuel use18.2 l/hourReference
Fuel use177.5 l/hourReference
Drawbar performanceReference
Fuel use17.8 l/hourReference
Gear 3II used for power test.Reference
Max pull2712 kgReference
Gear 1II used for pull test.Reference

General

Make & ModelNew HollandReference
SCV controljoystickReference
Rear Axle TypeFlange: 69.7 inch lengthReference
Rollover protective structureFlat deck platform with ROPS.Reference
Country of manufacturerItalyReference

Capacities

Capacity274 ciReference

PTO

PTO Power70 hpReference
Rear PTO PowerAvailableReference
Rear PTO RPM1,000 RPMReference
Engine Speed on Rear PTO speed540@2,199 | 1,000@2,261 RPMReference

Steering & brakes

Brakeshydraulic wet discReference
Steering typehydrostatic powerReference

Hydraulics

Hydraulics Typeopen centerReference
Maximum operating pressure2,871 psiReference
Remote Valves2 to 3 ValvesReference
Steering & Implements flow10.4 gpm (16.1 gpm)Reference
Rear Hitch category (SAE designation)Category IIReference
Rear Hitch Sensing Typemechanical lower-link draft sensingReference

Dimensions & weight

Height Over ROPS276.6 cmReference
Height Over Cab256 cmReference
Overall Length235 cmReference

Wheels & tyres

Front Wheel tread range58.8 to 82.4 inchesReference

Operator station

Cab AvailabilityAvailableReference
Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
