Tractor · 2019Unverified

New Holland T5.110 Dynamic/Auto Command

Name: New Holland T5.110 Dynamic/Auto Command
Brand: New Holland

New Holland T5.110 Dynamic/Auto Command — T5 Series · 99 hp. Reference specifications; pending source verification.

The New Holland T5.110 Dynamic/Auto Command is a tractor model with a rated power of 99 hp, positioned in the mid-range of its class. It features a 4-cylinder turbocharged diesel liquid-cooled engine, coupled with a four-wheel drive and a powershift transmission. The tractor has an operating weight of 5499 kg and is suitable for operations spanning 200–800 ac. It was manufactured in 2019.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

99 hp

Weight

5499 kg

Catalogue coverage

Variants represented

Richest spec table

67 rows

Recorded power

99 hp

Recorded weight

5499 kg

Transmissions

24-speed eight-speed power shift

Production years

2019-2019

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew Holland (a part of CNH)Reference

Utility tractorReference

Four-wheel driveReference

Differential lockelectro-hydraulic front and rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Cab standard with air-conditioning.Reference

Variants

Vestrum 100similar CaseIH modelReference

Engine

FPT 4.5L 4-cyl dieselReference

Fuel tank179.8 LReference

Exhaust fluid (DEF)18.9 LReference

Engine (gross)73.5 kWReference

Engine (max)80.9 kWReference

FPT NEFReference

turbocharged aftercooled dieselReference

4-cylinder 16-valveReference

liquid-cooledReference

Displacement4.5 LReference

Bore/Stroke104 x 132 mmReference

EmissionsTier IVReference

Rated Power (gross)73.5 kWReference

Maximum Power (gross)80.9 kWReference

Rated RPM2200Reference

Torque520.0 NmReference

Torque RPM1300Reference

StarterelectricReference

Starter volts12Reference

Transmission

continuously-variable transmissionReference

24-speed eight-speed power shiftReference

TransmissionAuto CommandReference

Typecontinuously-variable transmissionReference

Gearsinfinite forward and reverseReference

TransmissionDynamic CommandReference

Typeeight-speed power shiftReference

Gears24 forward and reverseReference

PTO & Hydraulics

Typeclosed center load-sensingReference

Pressure200.0 barReference

Rear valves4Reference

Mid valves3Reference

Pump flow79.9 lpmReference

Pump flow110.1 lpmReference

Steering flow36.3 lpmReference

Rear TypeIIReference

Controlelectronic draft controlReference

Rear lift (at ends)5499 kgReference

Rear lift (at 24"/610mm)4639 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulic wet discReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@1969Reference

Engine RPM540E@1546Reference

Engine RPM1000@1893Reference

Front PTOindependentReference

Dimensions

Wheelbase248 cmReference

Weight5499 kgReference

Length439 cmReference

Width228 cmReference

Shipping weight5499 kgReference

Max weight8799 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps120Reference

Charging amps200Reference

Battery volts12Reference

New Holland T5.110 Height

Hood189 cmReference

Cab269 cmReference

Cab279 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
