Tractor · 2013Unverified

New Holland T5.115

Name: New Holland T5.115
Brand: New Holland

New Holland T5.115 — T5 Series · 114 hp. Reference specifications; pending source verification.

The New Holland T5.115 is a mid-range tractor model with an engine rating of approximately 114 horsepower. It was manufactured between 2013 and 2016. The tractor features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. Its operating weight is listed at 4250 kg, making it suitable for operations of 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

114 hp

Max power

78.1 kW

Weight

4250 kg

Catalogue coverage

Variants represented

Richest spec table

82 rows

Recorded power

114 hp

Recorded weight

4250 kg

Transmissions

12-speed power shuttle

Production years

2013-2016

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew Holland (a part of CNH)Reference

Utility tractorReference

Four-wheel driveReference

Differential lockElectro-hydraulic rear. Limited slip front.Reference

Steeringhydrostatic powerReference

Hydraulic wet disc brakesReference

Cab standard with air-conditioning.Reference

Variants

T5.115base modelReference

T5.115 Electro Commandpremium modelReference

Farmall 115Usimilar CaseIH modelReference

Engine

FPT 3.4L 4-cyl dieselReference

Fuel tank140.0 LReference

Engine (gross)85.0 kWReference

Drawbar (tested)54.4 kWReference

FPT F5DReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.4 LReference

Bore/Stroke99 x 110 mmReference

EmissionsInterim Tier IVReference

Emission controlcooled exhaust gas recirculation with diesel particulate filter (DPF) (CEGR)Reference

Power (gross)85.0 kWReference

Pre-heatinggrid heaterReference

Rated RPM2300Reference

StarterelectricReference

Starter volts12Reference

Max power78.1 kWReference

Power at rated engine speed76.8 kWReference

Max power54.4 kWReference

Transmission

12-speed power shuttleReference

20-speed creeper power shuttleReference

24-speed two-speed power shiftReference

Typepower shuttleReference

Gears12 forward and reverseReference

Four synchronized gears in three non-synchronized ranges. Power shuttle shift.Reference

TransmissionFour synchronized gears in three non-synchronized ranges with added creeper range. Power shuttle shift.Reference

Typecreeper power shuttleReference

Gears20 forward and reverseReference

TransmissionDual CommandReference

Typetwo-speed power shiftReference

Gears24 forward and reverseReference

PTO & Hydraulics

PTO (claimed)73.1 kWReference

PTO (tested)78.1 kWReference

Typeopen center gear pumpsReference

Valves2 to 3Reference

Pump flow60.9 lpmReference

Pump flow79.9 lpmReference

Steering flow37.9 lpmReference

Steering flow43.1 lpmReference

Rear TypeIIReference

Controlelectronic draft controlReference

Rear lift (at 24"/610mm)2899 kgReference

Rear lift (at 24"/610mm)4741 kgReference

Rear Armsflexible lower link ends with telescopic stabilizersReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540/1000Reference

Front PTO Type1000Reference

Power at rated PTO speed78.1 kWReference

Dimensions

Wheelbase234 cmReference

Weight4250 kgReference

Length416 cmReference

Width209 cmReference

Height (cab)267 cmReference

New Holland T5.115 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps120Reference

Battery CCA960Reference

Battery volts12Reference

Attachment overview

New Holland 825TL loaderReference

New Holland 835TL loaderReference

Test results

Diesel 24-speed 4WDMarch 2013 - July 2013, Link: OCED Tractor Test 2803A fileReference

PTO performanceReference

Fuel use23.1 l/hourReference

Fuel use24.2 l/hourReference

Drawbar performanceReference

Fuel use24.6 l/hourReference

Gear 2MH used for power test.Reference

Max pull3733 kgReference

Gear 2ML used for pull test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
