Tractor · 2017Unverified

New Holland T5.90

Name: New Holland T5.90
Brand: New Holland

New Holland T5.90 — T5 Series · 90 hp. Reference specifications; pending source verification.

The New Holland T5.90 is a tractor with a rated power of 90 hp, a mid-range figure for its class. Manufactured in 2017, it features a 4-cylinder turbocharged diesel liquid-cooled engine, and is equipped with four-wheel drive and a powershift transmission. The T5.90 has an operating weight ranging from 7672 to 8157 pounds. It is suitable for operations covering areas of 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

90 hp

Weight

7672 to 8157 pounds

Catalogue coverage

Variants represented

Richest spec table

60 rows

Recorded power

90 hp

Recorded weight

3480 kg

Transmissions

24-speed two-speed power shift

Production years

2017-2017

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew Holland (a part of CNH)Reference

Utility tractorReference

Original price$86,490 (2023 ROPS )Reference

Original price$102,249 (2023 Cab )Reference

Four-wheel driveReference

Differential lockelectro-hydraulic rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Two-post ROPS. Cab available with air-conditioning.Reference

Engine

FPT 3.4L 4-cyl dieselReference

Fuel tank114.7 LReference

Exhaust fluid (DEF)10.6 LReference

Engine (gross)67.1 kWReference

FPT F5GReference

turbocharged dieselReference

4-cylinder 16-valveReference

liquid-cooledReference

Displacement3.4 LReference

Bore/Stroke99 x 110 mmReference

EmissionsTier IVReference

Power (gross)67.1 kWReference

StarterelectricReference

Starter volts12Reference

Transmission

24-speed two-speed power shiftReference

TransmissionDual CommandReference

Typetwo-speed power shiftReference

Gears24 forward and reverseReference

Four gears in three ranges with two-speed power shift and power shuttle. Optional creeper range provides 40 speeds.Reference

PTO & Hydraulics

PTO (claimed)54.4 kWReference

Typeopen centerReference

Rear valves2 or 3Reference

Mid valves2Reference

Pump flow64.0 lpmReference

Total flow100.7 lpmReference

Steering flow36.7 lpmReference

Rear TypeIIReference

Rear lift (at 24"/610mm)2549 kgReference

Rear lift (at 24"/610mm)3334 kgReference

Rear PTOindependentReference

Clutchhydraulic wet discReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase228 cmReference

Weight7672 to 8157 poundsReference

Front tire14.9R24Reference

Rear tire18.4R34Reference

Standard tires (ag)Front: 14.9R24. Rear: 18.4R34Reference

Length408 cmReference

Width192 cmReference

Height (ROPS)270 cmReference

Height (cab)259 cmReference

ROPS Weight3480 kgReference

Cab Weight3700 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps120Reference

Charging amps200Reference

Batteries12Reference

Battery CCA800Reference

Battery volts1Reference

Battery AH110Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
