Tractor · 2007Unverified
New Holland T6080 Elite
New Holland T6080 Elite — T6000 Series · 155 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
155 hp
Max power
111.6 kW
Weight
12346 to 14585 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Row-Crop tractorReference
Built in Basildon, EnglandReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Differential hydraulic wet disc brakesReference
Horizon cab standard with air-conditioning. Optional deluxe cab with automatic temperature control and air-ride seat. Optional Comfort Ride cab suspension. Programmable headland management system.Reference
Engine
FPT 6.7L 6-cyl dieselReference
Engine (gross)115.6 kWReference
Engine (max)123.8 kWReference
Drawbar (tested)77.2 kWReference
FPT NEFReference
turbocharged air-to-air intercooled dieselReference
6-cylinder 24-valveReference
liquid-cooledReference
Displacement6.7 LReference
Bore/Stroke104 x 132 mmReference
EmissionsTier 3Reference
Rated Power (gross)115.6 kWReference
Maximum Power (gross)123.8 kWReference
Fuel systemhigh pressure common rail (HPCR)Reference
Air cleanerdual paper elements and aspiratorReference
Compression17.5:1Reference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Oil capacity15.1 LReference
Max power111.6 kWReference
Power at rated engine speed101.5 kWReference
Max power77.2 kWReference
Transmission
18-speed full power shiftReference
TransmissionPower CommandReference
Typefull power shiftReference
Gears18 forward and 6 reverseReference
Clutchhydraulic wet discReference
PTO & Hydraulics
PTO (claimed)100.7 kWReference
PTO (tested)111.6 kWReference
Hydraulic system70.0 LReference
Typeclosed center load sensingReference
Capacity70.0 LReference
Valves2 to 4Reference
Pump flow100.3 lpmReference
Total flow165.0 lpmReference
Steering flow64.7 lpmReference
Rear Type2/3NReference
Controlelectronic lower-link draft controlReference
Rear lift5527 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Power at rated PTO speed105.3 kWReference
Capacities
Fuel300.2 LReference
Dimensions
Wheelbase273 cmReference
Wheelbase289 cmReference
Weight12346 to 14585 poundsReference
Height (cab)288 cmReference
Height (exhaust)285 cmReference
Shipping weight5600 kgReference
Operating weight6615 kgReference
Front tread157 to 233 cmReference
New Holland T6080 Elite attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps120Reference
Charging volts12Reference
Battery CCA1300Reference
Battery volts12Reference
Attachment overview
The 850TL loader is available with mechanical self-leveling (MSL).Reference
Test results
Diesel Range Command 4WDJuly 1 - November 1, 2008Link: OCED Tractor Test 2494 fileReference
PTO performanceReference
Fuel use31.8 l/hourReference
Fuel use32.6 l/hourReference
Drawbar performanceReference
Gear 3M used for power test.Reference
Max pull6404 kgReference
Gear 1L used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
