Tractor · 2012Unverified

New Holland T6.150

Name: New Holland T6.150
Brand: New Holland

New Holland T6.150 — T6 Series · 121 hp. Reference specifications; pending source verification.

The New Holland T6.150 is a tractor with a rated power of 121 hp, positioning it at the upper end of its class. It was produced during the 2012 to 2014 period. The tractor is equipped with a 4-cylinder turbocharged diesel liquid-cooled engine and four-wheel drive, paired with a continuously variable transmission. Its operating weight is listed at 4890 kg, suitable for operations spanning 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

121 hp

Max power

96.8 kW

Weight

4890 kg

Catalogue coverage

Variants represented

Richest spec table

91 rows

Recorded power

121 hp

Recorded weight

4890 kg

Transmissions

24-speed two-speed power shift

Production years

2012-2014

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Row-Crop tractorReference

Original price was $85,604 in 2014Reference

Four-wheel driveReference

Steeringhydrostatic powerReference

Hydraulic wet disc brakesReference

Horizon cab standard with air-conditioning. Optional deluxe high-profile roof. Optional cab suspension.Reference

Engine

FPT 4.5L 4-cyl dieselReference

Fuel tank174.9 LReference

Exhaust fluid (DEF)36.7 LReference

Engine (gross)90.2 kWReference

Engine (max)114.8 kWReference

Drawbar (tested)70.5 kWReference

FPTReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.5 LReference

Bore/Stroke104 x 132 mmReference

EmissionsInterim Tier IVReference

Emission controlselective catalytic reduction (SCR)Reference

Rated Power (gross)90.2 kWReference

Maximum Power (gross)114.8 kWReference

Rated RPM2200Reference

StarterelectricReference

Starter volts12Reference

Max power96.8 kWReference

Power at rated engine speed91.9 kWReference

Max power70.5 kWReference

Transmission

24-speed two-speed power shiftReference

16-speed eight-speed power shiftReference

16-speedReference

TransmissionDual CommandReference

Typetwo-speed power shiftReference

Gears24 forward and reverseReference

TransmissionElectroShiftReference

Typeeight-speed power shiftReference

Gears16 forward and reverseReference

Four push-button power shift gears in four ranges. Clutch free shifting between ranges 1-2 and 3-4. Power shuttle.Reference

TransmissionAutoShiftReference

AutoShift adds automatic shifting to the ElectroShift transmission. Also available in a 17-speed version with 40 KPH or 50 KPH top speed.Reference

PTO & Hydraulics

PTO (claimed)74.6 kWReference

PTO (tested)96.8 kWReference

Typeopen centerReference

Typeclosed center load sensing (optional)Reference

Rear valves2 to 4Reference

Mid valves2 or 3Reference

Pump flow70.0 lpmReference

Pump flow100.3 lpmReference

Total flow109.8 lpmReference

Total flow147.2 lpmReference

Total flow124.9 lpmReference

Steering flow46.9 lpmReference

Rear TypeIIReference

Controlelectronic draft controlReference

Rear lift (at 24"/610mm)3048 kgReference

Rear lift (at 24"/610mm)3619 kgReference

Front lift (at ends)3099 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Engine RPM540@1969Reference

Engine RPM1000@1924Reference

Front PTOoptionalReference

Front PTO Type1000Reference

Power at rated PTO speed95.1 kWReference

Dimensions

Weight4890 kgReference

Length429 cmReference

Width228 cmReference

Height (cab)280 cmReference

Height (cab)292 cmReference

Shipping weight4890 kgReference

Ground clearance47 cmReference

Front axle4WDReference

Front axleTerraGlide suspensionReference

Front axleSuperSteerReference

Flange rear axleReference

Bar rear axle2489 mmReference

Rear tread152 to 213 cmReference

New Holland T6.150 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

New Holland 835TL loaderReference

New Holland 845TL loaderReference

Test results

Diesel 16-speed 4WDJune 2012 - 2012, Link: OCED Tractor Test 2707 fileReference

PTO performanceReference

Fuel use26.5 l/hourReference

Drawbar performanceReference

Gear 7 used for power test.Reference

Max pull4731 kgReference

Gear 4 used for pull test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
