Tractor · 2015Unverified

New Holland T6.175 Auto Command

Name: New Holland T6.175 Auto Command
Brand: New Holland

New Holland T6.175 Auto Command — T6 Series · 122 hp. Reference specifications; pending source verification.

The New Holland T6.175 Auto Command is a tractor rated at approximately 122 horsepower, positioning it at the more powerful end of its class. It was produced in 2015. The model is equipped with a 4-cylinder turbocharged intercooled diesel liquid-cooled engine and four-wheel drive, paired with a continuously variable transmission. Its operating weight ranges from 10605 to 15245 pounds, making it suitable for operations covering 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

122 hp

Max power

101.1 kW

Weight

10605 to 15245 pounds

Catalogue coverage

Variants represented

Richest spec table

88 rows

Recorded power

122 hp

Transmissions

continuously variable transmission (CVT)

Production years

2015-2015

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew Holland (a part of CNH)Reference

Row-Crop tractorReference

Original price was $153,260 in 2015Reference

Four-wheel driveReference

Final drivesinboard planetaryReference

Wet disc brakesReference

Horizon cab standard with air-conditioning and Comfort Ride cab suspension. ISOBUS II ((Optional)); AutoGuidance ((Optional))Reference

Variants

T6.175 ValueeconomyReference

T6.175 Plusmid-specReference

T6.175 ElitepremiumReference

T6.175 CVTAutoCommandReference

Engine

FPT 4.5L 4-cyl dieselReference

Exhaust fluid (DEF)36.7 LReference

Engine108.1 kWReference

Drawbar (tested)65.9 kWReference

FPTReference

turbocharged air-to-air intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.5 LReference

Bore/Stroke104 x 132 mmReference

EmissionsTier IVReference

Emission controlselective catalytic reduction (SCR)Reference

Power108.1 kWReference

Maximum Power130.5 kWReference

Fuel systemelectronic high-pressure common rail direct injectionReference

Cooling systemviscous fanReference

Rated RPM2200Reference

StarterelectricReference

Starter volts12Reference

Max power101.1 kWReference

Power at rated engine speed90.9 kWReference

Max power65.9 kWReference

Transmission

continuously variable transmission (CVT)Reference

TransmissionAuto CommandReference

Typecontinuously variable transmission (CVT)Reference

Gearsinfinite forward and reverseReference

PTO & Hydraulics

PTO (claimed)89.5 kWReference

PTO (tested)101.1 kWReference

Typeclosed center load sensingReference

Rear valves3 to 4Reference

Mid valves0 to 3Reference

Pump flow124.9 lpmReference

Rear TypeIIReference

Rear TypeIII/IIReference

Rear lift (at ends)5283 kgReference

Front HitchoptionalReference

DrawbarCat. 3Reference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Front PTOoptionalReference

Power at rated PTO speed98.5 kWReference

Dimensions

Wheelbase264 cmReference

Suspension Wheelbase268 cmReference

SuperSteer Wheelbase278 cmReference

Weight10605 to 15245 poundsReference

Front tire380/85R28Reference

Rear tire460/85R38Reference

Ag front380/85R28Reference

Ag rear460/85R38Reference

Length454 cmReference

Suspension Length455 cmReference

SuperSteer Length465 cmReference

Front axle4WDReference

Front axleSuspended axleReference

Front axleSuperSteer axleReference

Flange rear axleReference

Bar rear axle92 by 2489 mmReference

6915 kgReference

Shipping4810 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps150Reference

Charging amps200Reference

Battery CCA1300Reference

Battery volts12Reference

Capacities

Max capacity8999 kgReference

New Holland T6.175 Auto Command Height

Cab213 cmReference

Cab201 cmReference

Exhaust213 cmReference

Test results

Diesel 16-speed 4WDMarch 2016 - April 2016, Link: OCED Tractor Test 2981 fileReference

PTO performanceReference

Fuel use28.4 l/hourReference

Drawbar performanceReference

Fuel use28.0 l/hourReference

Pull at 9KPHReference

Max pull5261 kgReference

Pull at 3KPHReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
