Tractor · 2014Unverified

New Holland T7.230

Name: New Holland T7.230
Brand: New Holland

New Holland T7.230 — T7 Series · 180 hp. Reference specifications; pending source verification.

The New Holland T7.230 tractor model is rated at 180 hp, positioning it among the higher-powered machines in its class. It was manufactured in 2014. The tractor features a 6-cylinder turbocharged diesel liquid-cooled engine, coupled with a continuously variable transmission and four-wheel drive. Its listed weight ranges from 15322 to 16094 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

180 hp

Max power

129.4 kW

Weight

15322 to 16094 pounds

Catalogue coverage

Variants represented

Richest spec table

100 rows

Recorded power

180 hp

Transmissions

18-speed full power shift

Production years

2014-2014

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew Holland (a part of CNH)Reference

Row-Crop tractorReference

Original price$177,210 (2017 18-speed )Reference

Original price$203,860 (2017 CVT )Reference

Four-wheel driveReference

Final drivesinboard planetaryReference

Power steeringReference

Wet disc brakesReference

Cab standard with air-conditioning. Optional Comfort Ride cab suspension.Reference

Engine

FPT 6.7L 6-cyl dieselReference

Fuel tank393.6 LReference

Exhaust fluid (DEF)49.2 LReference

Engine (gross)134.2 kWReference

Engine (max)167.8 kWReference

Drawbar (tested)87.4 kWReference

FPTReference

turbocharged dieselReference

6-cylinder 24-valveReference

liquid-cooledReference

Displacement6.7 LReference

Bore/Stroke104 x 132 mmReference

EmissionsTier IVReference

Emission controlselective catalytic reductionReference

Rated Power (gross)134.2 kWReference

Maximum Power (gross)167.8 kWReference

Fuel systemelectronic high-pressure common rail direct injectionReference

Cooling systemviscous fanReference

Rated RPM2200Reference

StarterelectricReference

Starter volts12Reference

Max power129.4 kWReference

Power at rated engine speed107.0 kWReference

Max power87.4 kWReference

Transmission

18-speed full power shiftReference

19-speed full power shiftReference

continuously-variable transmission (CVT)Reference

TransmissionPower CommandReference

Typefull power shiftReference

Gears18 forward and 6 reverseReference

Gears19 forward and 6 reverseReference

TransmissionAuto CommandReference

Typecontinuously-variable transmission (CVT)Reference

Gearsinfinite forward and reverseReference

PTO & Hydraulics

PTO (claimed)111.9 kWReference

PTO (tested)129.4 kWReference

Typeclosed center load-sensingReference

Rear valves4 or 5Reference

Mid valves3Reference

Pump flow121.1 lpmReference

Pump flow149.5 lpmReference

Pump flow170.3 lpmReference

Rear TypeIII/IIReference

Controlelectronic lower-link draft controlReference

Rear lift (at ends)5800 kgReference

Rear lift (at ends)7199 kgReference

Rear lift (at 24"/610mm)4286 kgReference

Rear lift (at 24"/610mm)4874 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Engine RPM540@1893Reference

Engine RPM540E@1569Reference

Engine RPM1000@1950Reference

Engine RPM1000E@1583Reference

Front PTOindependentReference

Front PTO Type1000Reference

Power at rated PTO speed128.0 kWReference

Dimensions

Standard Wheelbase288 cmReference

Suspension Wheelbase288 cmReference

SuperSteer Wheelbase297 cmReference

Weight15322 to 16094 poundsReference

Front tire380/85R34Reference

Rear tire480/80R46Reference

Standard tires (ag)Front: 380/85R34. Rear: 480/80R46Reference

Length577 cmReference

Width246 cmReference

Height (cab)311 cmReference

Front axle4WDReference

Front axleSuspended 4WDReference

Front axleSuperSteer 4WDReference

Flange rear axleReference

Bar rear axle91 mmReference

Standard Shipping6950 kgReference

Suspension Shipping7300 kgReference

SuperSteer Shipping7100 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps150Reference

Charging amps200Reference

Battery volts12Reference

Capacities

Max capacity13000 kgReference

Test results

Diesel CVT 4WDJune 2015 - April 2016, Link: OCED Tractor Test 2961 fileReference

PTO performanceReference

Fuel use36.0 l/hourReference

Fuel use33.7 l/hourReference

Fuel use36.7 l/hourReference

Drawbar performanceReference

Fuel use31.4 l/hourReference

Pull at 10 KPHReference

Max pull7532 kgReference

Pull at 5.5 KPHReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
