Tractor · 2011Unverified
New Holland T7.235
New Holland T7.235 — T7 Series · 185 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
185 hp
Max power
139.8 kW
Weight
15322 to 16094 pounds
Hover a source tag to verify
Overview
ManufacturerNew Holland (a part of CNH)Reference
Row-Crop tractorReference
Built in Basildon, EnglandReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Brakeshydraulic wet discReference
Brakesengine exhaust brakeReference
Trailer brakeshydraulicReference
Trailer brakespneumaticReference
Horizon cab standard with air-conditioning. Intellisteer optionalReference
Engine
FPT 6.7L 6-cyl dieselReference
Fuel tank393.6 LReference
Exhaust fluid (DEF)49.2 LReference
Engine (gross)138.0 kWReference
Engine (max)174.5 kWReference
Drawbar (tested)110.1 kWReference
FPTReference
turbocharged intercooled dieselReference
6-cylinder 24-valveReference
liquid-cooledReference
Displacement6.7 LReference
Bore/Stroke104 x 132 mmReference
EmissionsInterim Tier 4Reference
Emission controlselective catalytic reduction (SCR)Reference
Rated Power (gross)138.0 kWReference
Maximum Power (gross)174.5 kWReference
Fuel systemhigh pressure common railReference
Cooling systemviscous fanReference
Cooling systemreversible fanReference
Rated RPM2200Reference
Torque862.4 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Max power139.8 kWReference
Power at rated engine speed123.4 kWReference
Max power110.1 kWReference
Transmission
18-speed full power shiftReference
19-speed full power shiftReference
continuously-variable transmission (CVT)Reference
TransmissionPower CommandReference
Typefull power shiftReference
Gears18 forward and 6 reverseReference
Clutchelectro-hydraulic wet discReference
TransmissionPower Command EconReference
Gears19 forward and 6 reverseReference
TransmissionAutoCommandReference
Typecontinuously-variable transmission (CVT)Reference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)111.9 kWReference
PTO (tested)139.8 kWReference
Typeclosed center load sensingReference
Rear valves3 to 5Reference
Mid valves3Reference
Pump flow121.1 lpmReference
Pump flow149.5 lpmReference
Steering flow64.3 lpmReference
Rear TypeIII/IIReference
Controlelectronic draft controlReference
Rear lift (at ends)5800 kgReference
Rear lift (at 24"/610mm)4874 kgReference
Rear Armsflex link endsReference
Front HitchoptionalReference
Front lift (at ends)3784 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Rear PTO Type540E/1000Reference
Rear PTO Type1000/1000EReference
Front PTOindependentReference
Front PTO Type1000Reference
Power at rated PTO speed138.0 kWReference
Dimensions
Wheelbase288 cmReference
Wheelbase297 cmReference
Weight15322 to 16094 poundsReference
Rear tire20.8R42Reference
Ag rear20.8R42Reference
Length577 cmReference
Width246 cmReference
Height (cab)304 cmReference
Height (exhaust)311 cmReference
Ground clearance47 cmReference
Front axle4WDReference
Front axleTerraLockReference
Front axleSuperSteerReference
Flange rear axleReference
Bar rear axle2489 mmReference
Bar rear axle2844 mmReference
Bar rear axle3022 mmReference
Shipping6950 kgReference
Shipping7300 kgReference
Shipping7100 kgReference
New Holland T7.235 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps150Reference
Charging amps200Reference
Battery CCA1300Reference
Battery volts12Reference
Battery AH176Reference
Attachment overview
New Holland 850TL loaderReference
New Holland 860TL loaderReference
Capacities
Max capacity13000 kgReference
Test results
Diesel 19-speed 4WDDecember 2010 - April 2011, Link: OCED Tractor Test 2612 fileReference
PTO performanceReference
Fuel use36.3 l/hourReference
Fuel use34.8 l/hourReference
Drawbar performanceReference
Fuel use35.6 l/hourReference
Gear 10 used for power test.Reference
Max pull7554 kgReference
Gear 7 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
