Tractor · 2007Unverified

New Holland T7530

Name: New Holland T7530
Brand: New Holland

New Holland T7530 — T7500 Series · 158 hp. Reference specifications; pending source verification.

The New Holland T7530 is a tractor model with a rated output of 158 horsepower, positioning it within the higher-powered machines in its class. The T7530 was manufactured in 2007. This model features a 6-cylinder turbocharged intercooled liquid-cooled engine, which powers a four-wheel drive system via a continuously variable transmission. Its listed weight is 6491 kg, making it suitable for jobs covering approximately 200-800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

158 hp

Max power

157.8 hp

Weight

6491 kg

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

158 hp

Recorded weight

6491 kg

Transmissions

Continuously variable (CVT)

Production years

2007-2007

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Four-wheel driveReference

cab with A/CReference

Engine

6.6L 6-cylReference

Fuel tank310.0 LReference

Engine117.7 kWReference

intercooled turbochargedReference

6-cylinderReference

liquid-cooledReference

Displacement6.6 LReference

Bore/Stroke108 x 120 mmReference

Power117.7 kWReference

Rated RPM2100Reference

Torque659.8 NmReference

Torque RPM1400Reference

No of Cylinders6 cylinderReference

Rated engine speed2,100 rpmReference

Engine torque at rated speed220.7 kgReference

Bore and stroke4.252x4.724 inchesReference

Cooling systemliquid-cooledReference

PTO & Hydraulics

Typeclosed center load sensingReference

Pressure205.0 barReference

Valves0 to 5Reference

Pump flow104.8 lpmReference

Pump flow129.8 lpmReference

Rear PTO Type540/540E/1000/1000EReference

Front PTO Type1000Reference

Dimensions

Wheelbase280 cmReference

Weight6491 kgReference

Front tire540/65Reference

Rear tire650/65Reference

Ag front540/65 R28Reference

Ag rear650/65 R38Reference

Length473 cmReference

Width248 cmReference

Height299 cmReference

Shipping weight6491 kgReference

Ground clearance50 cmReference

Transmission

TransmissionContinuously variable (CVT)Reference

Gearsinfinite, 3-range forward and reverseReference

Transmission TypeCVTReference

forward and reverse optionsContinuously variable (CVT) : infinite(3-range) F and RReference

Wheel Drive4WDReference

Capacities

Capacity402.8 ciReference

Power

Max Power157.8 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 rpmReference

Front PTO PowerAvailableReference

General

Cruise controlAvailableReference

SCV controlJoystickReference

Hydraulics

Hydraulics Typeclosed center load sensingReference

Maximum operating pressure2,973 psiReference

Remote Valves0 to 5 valvesReference

Dimensions & weight

Overall Height300 cmReference

Overall Length474 cmReference

Overall Width248.9 cmReference

Overall weight6,490.9 kgReference

Wheels & tyres

Rear Wheel Type650/65 R38Reference

Front Wheel Type540/65 R28Reference

Operator station

Cab AvailabilityAvailableReference

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
