Tractor · 2015Unverified
New Holland T8.380 SmartTrax
New Holland T8.380 SmartTrax — T8 Series · 311 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
311 hp
Max power
236.9 kW
Weight
16233 kg
Hover a source tag to verify
Overview
ManufacturerNew Holland (a part of CNH)Reference
Half-track Crawler tractorReference
Original price was $387,743 in 2016 with powershiftReference
Drivehalf-trackReference
Final drivesinboard planetaryReference
Wet disc brakesReference
Cab standard with air-conditioning. Intellisteer readyReference
Variants
T8.380wheeled tractorReference
T8.380 SmartTraxhalf-trackReference
Engine
FPT 8.7L 6-cyl dieselReference
CVT Fuel tank617.0 LReference
FPS Fuel tank677.5 LReference
Exhaust fluid (DEF)98.4 LReference
Engine (gross)231.9 kWReference
Engine (max)284.9 kWReference
Drawbar (tested)169.5 kWReference
FPTReference
variable-geometry turbocharged dieselReference
6-cylinder 24-valveReference
liquid-cooledReference
Displacement8.7 LReference
Bore/Stroke117 x 135 mmReference
EmissionsTier IVReference
Emission controlselective catalytic reduction (SCR)Reference
Rated Power (gross)231.9 kWReference
Maximum Power (gross)284.9 kWReference
Fuel systemelectronic high-pressure common railReference
Cooling systemviscous fanReference
Rated RPM2000Reference
StarterelectricReference
Starter volts12Reference
Max power236.9 kWReference
Power at rated engine speed205.8 kWReference
Max power169.5 kWReference
Transmission
18-speed full power shiftReference
continuously variable transmission (CVT)Reference
TransmissionUltra-CommandReference
Typefull power shiftReference
Gears18 forward and 4 reverseReference
TransmissionAuto CommandReference
Typecontinuously variable transmission (CVT)Reference
Gearsinfinite forward and reverse (4-range)Reference
PTO & Hydraulics
PTO (claimed)197.6 kWReference
PTO (tested)236.9 kWReference
Typeclosed center pressure-flow compensating (PFC)Reference
Valves4 to 5Reference
Pump flow162.8 lpmReference
Pump flow276.3 lpmReference
Rear TypeIII/IIINReference
Rear TypeIVN/IIIReference
Controlelectronic lower-link draft sensingReference
Rear lift9026 kgReference
DrawbarCat. 3Reference
DrawbarCat. 4Reference
Rear PTOindependentReference
Rear PTO Type1000Reference
Rear PTO Type540/1000Reference
Front PTOindependentReference
Front PTO Type1000 (1.375)Reference
Power at rated PTO speed236.9 kWReference
Dimensions
Wheelbase355 cmReference
Weight16233 kgReference
Front tire380/80R42Reference
Rear tiretracksReference
Ag front380/80R42Reference
Ag rear18-inch tracksReference
Ag front420/85R38Reference
Ag front380/95R38Reference
Ag front420/75R30Reference
Ag rear16-inch tracksReference
Ag rear24-inch tracksReference
Ag rear30-inch tracksReference
Length660 cmReference
Height (cab)345 cmReference
Max weight16260 kgReference
Front axleMFWDReference
Front axleTerraglideReference
Front tread152 to 223 cmReference
Rear tread193 to 386 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps200Reference
Batteries2Reference
Battery volts12Reference
Test results
Diesel Power shift half-trackApril 21 - May 3, 2016Link: OCED Tractor Test 2148A fileReference
PTO performanceReference
Fuel use60.6 l/hourReference
Fuel use54.5 l/hourReference
Drawbar performanceReference
Gear 7 used for power test.Reference
Max pull14554 kgReference
Gear 2 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
