Tractor · 2013Unverified

New Holland T8.420

Name: New Holland T8.420
Brand: New Holland

New Holland T8.420 — Genesis T8 Series · 367 hp. Reference specifications; pending source verification.

The New Holland T8.420 is a high-powered tractor with a rated output of 367 hp, positioning it among the more powerful machines in its class. It was manufactured between 2013 and 2014. The tractor features a 6-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with a mechanical front-wheel drive system and a continuously variable transmission. Its listed weight is 13,682 kg, making it suitable for large-scale operations of around 1,500+ acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

367 hp

Max power

262.2 kW

Weight

13682 kg

Catalogue coverage

Variants represented

Richest spec table

76 rows

Recorded power

367 hp

Recorded weight

13682 kg

Transmissions

Auto Command CVT

Production years

2013-2014

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Row-Crop tractorReference

Built in Racine, Wisconsin, USAReference

Four-wheel driveReference

Final drivesinboard planetaryReference

Power steeringReference

Cab standard with air-conditioning.Reference

Engine

FPT 8.7L 6-cyl dieselReference

Fuel tank575.3 LReference

Exhaust fluid (DEF)89.3 LReference

Engine (gross)273.7 kWReference

Drawbar (tested)190.7 kWReference

FPT F2CReference

turbocharged intercooled dieselReference

6-cylinderReference

liquid-cooledReference

Displacement8.7 LReference

Bore/Stroke117 x 135 mmReference

EmissionsInterim Tier 4Reference

Emission controlselective catalytic reduction (SCR)Reference

Power (gross)273.7 kWReference

Maximum Power312.4 kWReference

Fuel systemelectronic high-pressure common railReference

Cooling systemviscous fanReference

Air cleanerdual dry elementReference

Compression15.9:1Reference

Rated RPM2000Reference

StarterelectricReference

Starter volts12Reference

Max power262.2 kWReference

Power at rated engine speed228.1 kWReference

Max power190.7 kWReference

Transmission

continuously variable transmissionReference

TransmissionAuto Command CVTReference

Typecontinuously variable transmissionReference

Gearsinfinite forward and reverse (4-range)Reference

PTO & Hydraulics

PTO (claimed)227.4 kWReference

PTO (tested)262.2 kWReference

Typeclosed center pressure flow compensatingReference

Valves4 to 6Reference

Pump flow166.5 lpmReference

Pump flow283.9 lpmReference

Rear TypeIVN/IIIReference

Controlelectronic lower-link draft sensingReference

Rear lift7938 kgReference

Rear lift8845 kgReference

Front HitchoptionalReference

Front lift5806 kgReference

DrawbarCat. 4Reference

Rear PTOindependentReference

Rear PTO Type1000Reference

Rear PTO Type540/1000Reference

Engine RPM1000@1778Reference

Power at rated PTO speed262.1 kWReference

Dimensions

Wheelbase355 cmReference

Weight13682 kgReference

Front tire420/85R34L480/80R50Reference

Standard tires (ag)Front: 420/85R34L480/80R50. Rear:Reference

Length647 cmReference

Operating weight13682 kgReference

Front axleMFWDReference

Front axleTerraglideReference

Bar rear axle127 by 3048 mmReference

T8.420 Serial Number Location

Serial number plate on the front-right of the tractor frame.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps200Reference

Battery volts12Reference

Test results

Diesel CVT 4WDJuly 14 - 15, 2014Link: OCED Tractor Test 2086A fileReference

PTO performanceReference

Fuel use69.6 l/hourReference

Fuel use62.5 l/hourReference

Drawbar performanceReference

Pull at 8.3 KPHReference

Max pull12920 kgReference

Pull at 4.86 KPHReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
