Tractor · 2014Unverified

New Holland T9.480

Name: New Holland T9.480
Brand: New Holland

New Holland T9.480 — T9 Series · 420 hp. Reference specifications; pending source verification.

The New Holland T9.480 is a tractor with a rated power of 420 hp, placing it at the high-power end of its class. It was manufactured from 2014 to 2023. The tractor features a 6-cylinder turbocharged diesel liquid-cooled engine and four-wheel drive with a hydrostatic transmission. It has a listed operating weight of 16351 kg, suitable for operations covering over 1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

420 hp

Max power

308.3 kW

Weight

16351 kg

Catalogue coverage

Variants represented

Richest spec table

95 rows

Recorded power

420 hp

Recorded weight

16351 kg

Transmissions

17-speed full power shift

Production years

2014-2023

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew Holland (a part of CNH)Reference

Four-wheel Drive (4WD) tractorReference

Built in Fargo, North Dakota, USAReference

Four-wheel driveReference

Steeringhydrostatic power articulatedReference

Wet disc brakesReference

Trailer brakeshydraulicReference

Cab standard with air-condioning. Optional Comfort Ride cab suspension. ISOBUS compliant; Intelliview IV; IntelliSteerReference

Variants

Steiger 420similar CaseIH modelReference

Engine

FPT 12.9L 6-cyl dieselReference

Fuel tank870.6 LReference

Exhaust fluid (DEF)159.0 LReference

Engine (gross)313.2 kWReference

Engine (max)344.5 kWReference

Drawbar (tested)254.2 kWReference

FPT Cursor 13 SSTReference

wastegate turbocharged aftercooled dieselReference

6-cylinder 24-valveReference

liquid-cooledReference

Displacement12.9 LReference

Bore/Stroke135 x 150 mmReference

EmissionsTier IVReference

Emission controlselective catalytic reduction with diesel oxidation catalystReference

Rated Power (gross)313.2 kWReference

Maximum Power (gross)344.5 kWReference

Fuel systemelectronic direct-injection high pressure common railReference

Cooling systemviscous fan driveReference

Rated RPM2100Reference

Torque1992.0 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Max power308.3 kWReference

Power at rated engine speed274.0 kWReference

Max power254.2 kWReference

Transmission

17-speed full power shiftReference

TransmissionUltra CommandReference

Typefull power shiftReference

Gears17 forward and 2 reverseReference

PTO & Hydraulics

PTO (claimed)264.7 kWReference

PTO (tested)308.3 kWReference

Typeclosed center load sensing (CCLS)Reference

Valves4 to 8Reference

Standard Pump flow159.0 lpmReference

High-Flow Pump flow215.7 lpmReference

MegaFlow Pump flow427.7 lpmReference

Rear TypeIVNReference

Rear TypeIIINReference

Controlposition controlReference

Rear lift (at 24"/610mm)9072 kgReference

Rear Armsadjustable link endsReference

DrawbarCat. 4Reference

Rear PTOindependentReference

Rear PTO Type1000 (1.75)Reference

Engine RPM1000@1998 (early)Reference

Engine RPM1000@1811 (late)Reference

Power at rated PTO speed303.9 kWReference

Dimensions

Wheelbase375 cmReference

Weight16351 kgReference

Front tire710/70Reference

Rear tire710/70Reference

Ag front710/70 R42Reference

Ag rear710/70 R42Reference

Length739 cmReference

Width304 cmReference

Height (cab)384 cmReference

Shipping weight16351 kgReference

Max weight22453 kgReference

Front axle127 by 3048 mmReference

Bar rear axle127 by 3048 mmReference

T9.480 Serial Numbers

2014ZDFxxxxxxReference

2015ZEFxxxxxxReference

2016ZFFxxxxxxReference

2017ZGFxxxxxxReference

2018ZHFxxxxxxReference

2019ZJFxxxxxxReference

2020ZKFxxxxxxReference

2021ZLFxxxxxxReference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps200Reference

Batteries2Reference

Battery CCA1000Reference

Battery volts12Reference

Test results

Diesel 16-speed 4WDSeptember 23 - October 1, 2014Link: OCED Tractor Test 2093A fileReference

PTO performanceReference

Fuel use85.2 l/hourReference

Fuel use81.4 l/hourReference

Fuel use82.1 l/hourReference

Drawbar performanceReference

Fuel use81.0 l/hourReference

Gear 4 used for power test.Reference

Max pull18943 kgReference

Gear 1 used for pull test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
