Tractor · 1999Unverified
New Holland TC18
New Holland TC18 — Boomer TC Series · 19 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
19 hp
Weight
1357 to 1438 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Compact Utility tractorReference
Original price was $9000 in 2000Reference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post fixed ROPS.Reference
Engine
Shibura 1.0L 3-cyl dieselReference
Fuel tank20.1 LReference
Engine (gross)13.8 kWReference
ShiburaReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke75 x 72 mmReference
Power (gross)13.8 kWReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
Starter volts12Reference
Transmission
6-speed gearReference
hydrostaticReference
TypegearReference
Gears6 forward and 2 reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
Gear PTO (claimed)11.2 kWReference
Hydro PTO (claimed)10.4 kWReference
Typeopen centerReference
Valves2Reference
Pump flow15.1 lpmReference
Total flow25.5 lpmReference
Steering flow10.4 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)573 kgReference
Gear Rear PTOtransmissionReference
Hydro Rear PTOliveReference
Rear PTO Type540Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Dimensions
Wheelbase140 cmReference
Weight1357 to 1438 poundsReference
Front tire4.00-12Reference
Rear tire8.00-16Reference
Ag front4.00-12 (2WD)Reference
Ag front5x12 (4WD)Reference
Ag front6x12 (4WD)Reference
Ag rear8.00-16Reference
Ag rear9.5x16 (4WD)Reference
Lawn/turf front20x8.00-10Reference
Lawn/turf front22x9.00-12Reference
Lawn/turf rear29x12.00-15Reference
Lawn/turf rear31x13.50-15Reference
Industrial front12x6.15Reference
Length270 cmReference
Width104 cmReference
Height (ROPS)203 cmReference
2WD Shipping weight615 kgReference
4WD Shipping weight652 kgReference
Ground clearance25 cmReference
Front tread82 cmReference
Rear tread85 cmReference
New Holland TC18 attachments
54" mid-mount mower deckReference
60" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
TC18 Serial Number Location
Serial number plate on the left side of the Boomer TC18 tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps20Reference
Battery volts12Reference
Attachment overview
54" mid-mount mower deckReference
60" mid-mount mower deckReference
SnowblowerReference
BladeReference
New Holland 7106 loaderReference
New Holland 12LA loaderReference
BackhoeReference
New Holland 756C Backhoe
Backhoe typeNew Holland 756C BackhoeReference
Transport height173 cmReference
2-Foot flat digging depth182 cmReference
8-Foot flat digging depth142 cmReference
Reach from pivot271 cmReference
Loading height144 cmReference
Bucket Rotation171°Reference
Swing Arc180°Reference
Bucket force1304 kgReference
Dipperstick force791 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
