Tractor · 2003Unverified
New Holland TC21DA
New Holland TC21DA — Boomer TC-A Series · 21 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
21 hp
Weight
698 kg
Hover a source tag to verify
Overview
ManufacturerNew Holland (a part of CNH)Reference
Compact Utility tractorReference
Original price was $12,500 in 2000Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Soft cab optional.Reference
Variants
Farmall DX21similar CaseIH modelReference
Engine
Shibaura 1.0L 3-cyl dieselReference
Fuel tank20.1 LReference
Engine (gross)15.7 kWReference
Shibaura S773Reference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.0 LReference
Bore/Stroke77 x 72 mmReference
Power (gross)15.7 kWReference
Air cleanertwo-stage dryReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
9-speed gearReference
hydrostaticReference
TypegearReference
Gears9 forward and 3 reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Gear PTO (claimed)12.7 kWReference
Hydro PTO (claimed)11.9 kWReference
Typeopen centerReference
Valves2Reference
Pump flow18.5 lpmReference
Total flow29.0 lpmReference
Steering flow10.4 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)573 kgReference
Gear Rear PTOtransmissionReference
Hydro Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Gear Mid PTOtransmissionReference
Hydro Mid PTOindependentReference
Mid PTO Type2000Reference
Dimensions
Wheelbase146 cmReference
Weight698 kgReference
Front tire6-12Reference
Rear tire9.5-16Reference
Ag front6-12Reference
Ag rear9.5-16Reference
Ag front5-12Reference
Ag rear8x16Reference
Lawn/turf front22x9.00-12Reference
Lawn/turf rear31x13.5-15Reference
Industrial front23x8.50-12Reference
Industrial rear12x16.5Reference
New Holland TC21DA attachments
54" mid-mount mower deckReference
60" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
TC21DA Serial Number Location
Serial number plate on the left side of the transmission housing.Reference
TC21DA Serial Numbers
2004HF10001Reference
2005HF10161Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery volts12Reference
Battery AH36Reference
Attachment overview
54" mid-mount mower deckReference
60" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
