New Holland TC24DA

Name: New Holland TC24DA
Brand: New Holland

New Holland TC24DA — Boomer TC-A Series · 24 hp. Reference specifications; pending source verification.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

24 hp

Hover a source tag to verify

Overview

ManufacturerNew Holland (a part of CNH)Reference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Soft cab optional.Reference

Variants

Farmall DX24similar CaseIH modelReference

Engine

Shibaura 1.1L 3-cyl dieselReference

Fuel tank20.1 LReference

Engine (gross)17.9 kWReference

ShibauraReference

dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement1.1 LReference

Bore/Stroke77 x 81 mmReference

Power (gross)17.9 kWReference

StarterelectricReference

Starter volts12Reference

Transmission

9-speed gearReference

hydrostaticReference

TypegearReference

Gears9 forward and 3 reverseReference

TypehydrostaticReference

Gearsinfinite forward and reverseReference

PTO & Hydraulics

Gear PTO (claimed)14.5 kWReference

Hydro PTO (claimed)13.8 kWReference

Typeopen centerReference

Valves2Reference

Pump flow18.5 lpmReference

Total flow29.0 lpmReference

Steering flow10.4 lpmReference

Rear TypeIReference

Rear lift (at 24"/610mm)573 kgReference

Gear Rear PTOtransmissionReference

Hydro Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Gear Mid PTOtransmissionReference

Hydro Mid PTOindependentReference

Mid PTO Type2000Reference

Dimensions

Wheelbase146 cmReference

Front tire5-12Reference

Rear tire9.5-16Reference

Ag front5-12Reference

Ag rear9.5-16Reference

Ag front6-12Reference
