Tractor · 1999Unverified

New Holland TC33

Name: New Holland TC33
Brand: New Holland

New Holland TC33 — Boomer TC Series · 33 hp. Reference specifications; pending source verification.

The New Holland TC33 is a tractor with a rated power of 33 hp, situated at the lighter end of its class. Built from 1999 to 2003, it features a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. The listed operating weight ranges from 2334 to 2588 pounds. It is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

33 hp

Weight

2334 to 2588 pounds

Catalogue coverage

Variants represented

Richest spec table

103 rows

Recorded power

33 hp

Transmissions

9-speed gear

Production years

1999-2003

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Compact Utility tractorReference

Original price was $17,000 in 2000Reference

Two- or four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post ROPS. Folding ROPS on hydrostatic (D) model.Reference

Variants

TC33gearReference

TC33DhydrostaticReference

Engine

Shibaura 1.5L 3-cyl dieselReference

Fuel tank27.6 LReference

Engine (gross)24.6 kWReference

ShibauraReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke84 x 90 mmReference

Power (gross)24.6 kWReference

Pre-heatingglow plugsReference

Rated RPM2800Reference

Starter volts12Reference

Transmission

9-speed gearReference

hydrostaticReference

TypegearReference

Gears9 forward and 3 reverseReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

Gear PTO (claimed)21.3 kWReference

Hydro PTO (claimed)20.1 kWReference

Typeopen centerReference

Gear Pump flow25.0 lpmReference

Hydro Pump flow28.8 lpmReference

Gear Total flow38.2 lpmReference

Hydro Total flow48.1 lpmReference

Gear Steering flow13.2 lpmReference

Hydro Steering flow19.3 lpmReference

Rear TypeIReference

Rear lift (at 24"/610mm)741 kgReference

Gear Rear PTOtransmissionReference

Hydro Rear PTOliveReference

Rear PTO Type540Reference

Mid PTOoptionalReference

Mid PTO Type2000Reference

Dimensions

Wheelbase160 cmReference

SuperSteer Wheelbase182 cmReference

Weight2334 to 2588 poundsReference

Front tire5.50-16Reference

Rear tire11.2-24Reference

Ag front5.50-16 (2WD)Reference

Ag front7.00-14 (4WD)Reference

Ag rear11.2-24Reference

Lawn/turf front23x8.50-12 (2WD)Reference

Lawn/turf front23x8.50-14 (4WD)Reference

Lawn/turf rear13.6x16Reference

Lawn/turf front25/10.50LLx15Reference

Lawn/turf rear41/18LLx16.1Reference

Industrial front25x8.50-14Reference

Industrial rear15x19.5Reference

2WD Length270 cmReference

4WD Length269 cmReference

SuperSteer Length292 cmReference

Width137 cmReference

Height (ROPS)223 cmReference

Ground clearance35 cmReference

Front tread110 cmReference

Rear tread108 cmReference

2WD Shipping1058 kgReference

4WD Shipping1122 kgReference

SuperSteer Shipping1173 kgReference

New Holland TC33 attachments

60" mid-mount mower deckReference

72" mid-mount mower deckReference

snowblowerReference

bladeReference

front-end loaderReference

backhoeReference

TC33 Serial Numbers

1998G003207Reference

1999G010499Reference

2000G017605Reference

2001G026729Reference

2002G035134Reference

2003G039436Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

60" mid-mount mower deckReference

72" mid-mount mower deckReference

SnowblowerReference

BladeReference

Front-end loaderReference

BackhoeReference

New Holland 757C Backhoe

Backhoe typeNew Holland 757C BackhoeReference

Transport height190 cmReference

2-Foot flat digging depth228 cmReference

8-Foot flat digging depth190 cmReference

Reach from pivot302 cmReference

Loading height167 cmReference

Bucket Rotation170°Reference

Swing Arc180°Reference

Bucket force1213 kgReference

Dipperstick force954 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
