Tractor · 2000Unverified
New Holland TC35
New Holland TC35 — Boomer TC Series · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
2947 to 3421 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Power steeringReference
Two-post ROPS.Reference
Variants
TC35gearReference
TC35DhydrostaticReference
D35similar CaseIH modelReference
DX35similar CaseIH modelReference
Engine
Shibaura 1.7L 3-cyl dieselReference
Fuel tank49.2 LReference
Engine (gross)26.1 kWReference
ShibauraReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.7 LReference
Bore/Stroke84 x 100 mmReference
Power (gross)26.1 kWReference
Rated RPM2600Reference
Starter volts12Reference
Transmission
12-speed synch shuttleReference
hydrostaticReference
Typesynch shuttleReference
Gears12 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Gear PTO (claimed)22.1 kWReference
Hydro PTO (claimed)21.7 kWReference
Typeopen centerReference
Pressure156.9 barReference
Pump flow37.1 lpmReference
Total flow56.4 lpmReference
Steering flow19.3 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)918 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Mid PTOoptionalReference
Dimensions
Wheelbase186 cmReference
SuperSteer Wheelbase205 cmReference
Weight2947 to 3421 poundsReference
Front tire5.50x16Reference
Rear tire13.6x24Reference
Ag front5.50x16 (2WD)Reference
Ag front7.5Lx15 (2WD)Reference
Ag front7x16 (4WD)Reference
Ag front8x16 (4WD)Reference
Ag rear13.6x24Reference
Ag rear14.9x24Reference
Lawn/turf front25x8.50-14 (2WD)Reference
Lawn/turf front27x8.50-15 (4WD)Reference
Lawn/turf rear44x18-20Reference
Lawn/turf front27/12LLx15 (4WD)Reference
Lawn/turf rear22.5LLx16.1 (4WD)Reference
Industrial front10x16.5 (4WD)Reference
Industrial rear17.5Lx24 (4WD)Reference
Length318 cmReference
SuperSteer Length329 cmReference
Width155 cmReference
Height (ROPS)241 cmReference
Ground clearance35 cmReference
Front tread117 cmReference
Rear tread120 cmReference
TC35 2WD Shipping1336 kgReference
TC35 4WD Shipping1404 kgReference
TC35D Shipping1475 kgReference
TC35D Super Steer Shipping1551 kgReference
New Holland TC35 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
New Holland 16LA loaderReference
New Holland 17LA loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
