Tractor · 2001Unverified

New Holland TC40

Name: New Holland TC40
Brand: New Holland

New Holland TC40 — Boomer TC Series · 40 hp. Reference specifications; pending source verification.

The New Holland TC40 is a compact tractor, rated at 40 hp, positioned among its class. Manufactured from 2001 to 2003, this model is equipped with a 4-cylinder diesel liquid-cooled engine, driving four-wheel drive via a hydrostatic transmission. The tractor weighs between 2998 and 3497 pounds. It is designed for use on plots of around 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

40 hp

Weight

2998 to 3497 pounds

Catalogue coverage

Variants represented

Richest spec table

74 rows

Recorded power

40 hp

Transmissions

12-speed synch shuttle

Production years

2001-2003

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Compact Utility tractorReference

Two- or four-wheel driveReference

Power steeringReference

Two-post ROPS.Reference

Variants

TC40gearReference

TC40DhydrostaticReference

D40similar CaseIH modelReference

DX40similar CaseIH modelReference

Engine

Shibaura 2.0L 4-cyl dieselReference

Fuel tank49.2 LReference

Engine (gross)29.8 kWReference

Shibaura N844Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.0 LReference

Bore/Stroke84 x 90 mmReference

Power (gross)29.8 kWReference

Rated RPM2600Reference

Starter volts12Reference

Transmission

12-speed synch shuttleReference

hydrostaticReference

Typesynch shuttleReference

Gears12 forward and reverseReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

PTO & Hydraulics

Gear PTO (claimed)26.1 kWReference

Hydro PTO (claimed)24.8 kWReference

Typeopen centerReference

Pump flow37.1 lpmReference

Total flow56.4 lpmReference

Steering flow19.3 lpmReference

Rear TypeIReference

Rear lift (at 24"/610mm)1056 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Mid PTOoptionalReference

Mid PTO Type2000Reference

Dimensions

Wheelbase186 cmReference

SuperSteer Wheelbase205 cmReference

Weight2998 to 3497 poundsReference

Front tire5.50x16Reference

Rear tire13.6x24Reference

Ag front5.50x16 (2WD)Reference

Ag front7.5Lx15 (2WD)Reference

Ag front7x16 (4WD)Reference

Ag front8x16 (4WD)Reference

Ag rear13.6x24Reference

Ag rear14.9x24Reference

Lawn/turf front25x8.50-14 (2WD)Reference

Lawn/turf front27x8.50-15 (4WD)Reference

Lawn/turf rear44x18-20Reference

Lawn/turf front27/12LLx15 (4WD)Reference

Lawn/turf rear22.5LLx16.1 (4WD)Reference

Industrial front10x16.5Reference

Industrial rear17.5Lx24Reference

Length318 cmReference

SuperSteer Length328 cmReference

Width155 cmReference

Height (ROPS)241 cmReference

Ground clearance35 cmReference

Front tread117 cmReference

Rear tread120 cmReference

2WD Shipping1359 kgReference

4WD Shipping1427 kgReference

4WD Shipping1509 kgReference

4WD SuperSteer Shipping1586 kgReference

New Holland TC40 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

New Holland 16LA loaderReference

New Holland 17LA loaderReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
