Tractor · 2001Unverified

New Holland TC45

Name: New Holland TC45
Brand: New Holland

New Holland TC45 — Boomer TC Series · 45 hp. Reference specifications; pending source verification.

The New Holland TC45 is a tractor model with a rated engine power of approximately 45 hp, positioning it within the lighter category of its class. The model was in production from 2001 to 2003. It features a 4-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. The operating weight of the TC45 ranges from 3200 to 3586 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

45 hp

Weight

3200 to 3586 pounds

Catalogue coverage

Variants represented

Richest spec table

72 rows

Recorded power

45 hp

Transmissions

12-speed synch shuttle

Production years

2001-2003

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Compact Utility tractorReference

Two- or four-wheel driveReference

Power steeringReference

Two-post ROPS.Reference

Variants

TC45gearReference

TC45DhydrostaticReference

D45similar CaseIH modelReference

DX45similar CaseIH modelReference

Engine

Shibaura 2.2L 4-cyl dieselReference

Fuel tank49.2 LReference

Engine (gross)33.6 kWReference

Shibaura N844LReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.2 LReference

Bore/Stroke84 x 100 mmReference

Power (gross)33.6 kWReference

Rated RPM2600Reference

Starter volts12Reference

Transmission

12-speed synch shuttleReference

hydrostaticReference

Typesynch shuttleReference

Gears12 forward and reverseReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

PTO & Hydraulics

Gear PTO (claimed)29.5 kWReference

Hydro PTO (claimed)28.2 kWReference

Typeopen centerReference

Pump flow37.1 lpmReference

Total flow56.4 lpmReference

Steering flow19.3 lpmReference

Rear TypeIReference

Rear lift (at 24"/610mm)1056 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Dimensions

Wheelbase186 cmReference

SuperSteer Wheelbase205 cmReference

Weight3200 to 3586 poundsReference

Front tire5.50x16Reference

Rear tire13.6x24Reference

2WD Ag front5.50x16Reference

2WD Ag front7.5Lx15Reference

4WD Ag front7x16Reference

4WD Ag front8x16Reference

Ag rear13.6x24Reference

Ag rear14.9x24Reference

2WD Lawn/turf front25x8.50-14Reference

4WD Lawn/turf front27x8.50-15Reference

Lawn/turf rear44x18-20Reference

4WD Lawn/turf front27/12LLx15Reference

4WD Lawn/turf rear22.5LLx16.1Reference

4WD Industrial front10x16.5Reference

4WD Industrial rear17.5Lx24Reference

Length318 cmReference

SuperSteer Length329 cmReference

Width155 cmReference

Height (ROPS)241 cmReference

Ground clearance35 cmReference

Front tread117 cmReference

Rear tread120 cmReference

TC45 2WD Shipping1451 kgReference

TC45 4WD Shipping1519 kgReference

TC45D 4WD Shipping1549 kgReference

TC45D SuperSteer Shipping1626 kgReference

New Holland TC45 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

New Holland 16LA loaderReference

New Holland 17LA loaderReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
