Tractor · 2003Unverified

New Holland TC48DA

Name: New Holland TC48DA
Brand: New Holland

New Holland TC48DA — Boomer TC-A Series · 48 hp. Reference specifications; pending source verification.

The New Holland TC48DA is a compact tractor with a rated output of 48 hp, produced from 2003 to 2008. It features a 4-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and a 12-speed gearbox. The listed weight of the tractor is 1957 kg, indicating its suitability for tasks on land areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

48 hp

Weight

1957 kg

Catalogue coverage

Variants represented

Richest spec table

77 rows

Recorded power

48 hp

Recorded weight

1957 kg

Transmissions

12-speed synch shuttle

Production years

2003-2008

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Compact Utility tractorReference

The New Holland Boomer TC48DA was unable to make the advertised 3-point lift of 3,465 pounds or 12 GPM of hydraulic flow during official testing. Measured performance was a lift of 2,789 pounds and a flow rate of 11.3 GPM.Reference

Two- or four-wheel driveReference

Power steeringReference

Differential mechanical wet disc brakesReference

Two-post folding ROPS. Canopy optional.Reference

Variants

Farmall DX48similar CaseIH modelReference

Engine

Shibaura 2.2L 4-cyl dieselReference

Fuel tank51.1 LReference

Engine (gross)35.8 kWReference

Shibaura N844LReference

dieselReference

4-cylinderReference

liquid-cooled inlineReference

Displacement2.2 LReference

Bore/Stroke84 x 100 mmReference

Power (gross)35.8 kWReference

Air cleanerdual dry elementReference

Compression22.4:1Reference

Rated RPM2800Reference

Starter volts12Reference

Power at rated engine speed30.6 kWReference

Transmission

12-speed synch shuttleReference

Typesynch shuttleReference

Gears12 forward and reverseReference

PTO & Hydraulics

PTO (claimed)29.8 kWReference

PTO (tested)30.6 kWReference

Typeopen centerReference

Valves3Reference

Total flow45.4 lpmReference

Steering flow20.9 lpmReference

Rear TypeII/IReference

Rear lift (at 24"/610mm)1571 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2475Reference

Power at rated PTO speed28.8 kWReference

Dimensions

Wheelbase189 cmReference

Weight1957 kgReference

Front tire9.5L-15Reference

Rear tire14.9-28Reference

Weight665 kgReference

Ag front9.5L-15Reference

Ag rear14.9-28Reference

Ag front8-16 (4WD)Reference

Ag rear14.9-24Reference

Lawn/turf front27x10.5-15R3Reference

Lawn/turf rear44x18-20R3Reference

Industrial front11L-15SLReference

Industrial rear18.4-24R4Reference

Length348 cmReference

Width163 cmReference

Height231 cmReference

Operating weight1957 kgReference

New Holland TC48DA attachments

bladeReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

BladeReference

Front-end loaderReference

BackhoeReference

New Holland 759C Backhoe

Backhoe typeNew Holland 759C BackhoeReference

Transport height241 cmReference

2-Foot flat digging depth289 cmReference

8-Foot flat digging depth243 cmReference

Reach from pivot378 cmReference

Loading height243 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1995 kgReference

Dipperstick force1270 kgReference

Test results

Diesel 12-speed 4WDApril 27 - 30, 2004Link: Nebraska Tractor Test 1836 fileReference

PTO performanceReference

Fuel use12.9 l/hourReference

Fuel use11.4 l/hourReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
