Tractor · 2003Unverified
New Holland TC55DA
New Holland TC55DA — Boomer TC-A Series · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Weight
1922 kg
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Compact Utility tractorReference
Built in Dublin, Georgia, USAReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Canopy optional.Reference
Variants
Farmall DX55similar CaseIH modelReference
Engine
Shibaura 2.2L 4-cyl dieselReference
Fuel tank51.1 LReference
Engine (gross)41.0 kWReference
Shibaura N844LReference
turbocharged dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement2.2 LReference
Bore/Stroke84 x 100 mmReference
Power (gross)41.0 kWReference
Air cleanerdual dry elementReference
Compression22.4:1Reference
Rated RPM2700Reference
Starter volts12Reference
Power at rated engine speed35.8 kWReference
Transmission
12-speed mechanical shuttleReference
12-speed power shuttleReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Clutchdry discReference
Four synchronized gears in three ranges.Reference
TransmissionElectro-Hydraulic Shuttle Shift (EHSS)Reference
Typepower shuttleReference
PTO & Hydraulics
PTO (claimed)35.0 kWReference
PTO (claimed)34.3 kWReference
PTO (tested)35.8 kWReference
Typeopen centerReference
Valves3Reference
Pump flow43.9 lpmReference
Steering flow20.9 lpmReference
Rear TypeII/IReference
Rear lift (at 24"/610mm)1571 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2475Reference
Power at rated PTO speed35.6 kWReference
Dimensions
Wheelbase189 cmReference
Weight1922 kgReference
Front tire9.5L-15Reference
Rear tire14.9-28Reference
Weight665 kgReference
Ag front9.5L-15Reference
Ag rear14.9-28Reference
Ag front8-16 (4WD)Reference
Ag rear14.9-24Reference
Lawn/turf front27x10.5-15R3Reference
Lawn/turf rear44x18-20R3Reference
Industrial front11L-15SLReference
Industrial rear18.4-24R4Reference
Length348 cmReference
Width163 cmReference
Height231 cmReference
New Holland TC55DA attachments
bladeReference
front-end loaderReference
backhoeReference
TC55DA Serial Numbers
2004HX10001Reference
2005HX11615Reference
2006HX12946Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
BladeReference
Front-end loaderReference
BackhoeReference
New Holland 759C Backhoe
Backhoe typeNew Holland 759C BackhoeReference
Transport height241 cmReference
2-Foot flat digging depth289 cmReference
8-Foot flat digging depth243 cmReference
Reach from pivot378 cmReference
Loading height243 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1995 kgReference
Dipperstick force1270 kgReference
Test results
Diesel 12-speed 4WDApril 29 - 30, 2004Link: Nebraska Tractor Test 1837 fileReference
PTO performanceReference
Fuel use14.8 l/hourReference
Fuel use14.0 l/hourReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
