Tractor · 2002Unverified

New Holland TG230

Name: New Holland TG230
Brand: New Holland

New Holland TG230 — TG Series · 193 hp. Reference specifications; pending source verification.

The New Holland TG230 is a tractor with an engine output of approximately 193 horsepower, placing it towards the upper end of its class. It was manufactured between 2002 and 2006. The tractor features a 6-cylinder turbocharged diesel liquid-cooled engine, coupled with four-wheel drive and a powershift transmission. Its operating weight is specified as 19582 to 20382 pounds, and it is designed for use in areas of 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

193 hp

Max power

161.3 kW

Weight

19582 to 20382 pounds

Catalogue coverage

Variants represented

Richest spec table

96 rows

Recorded power

193 hp

Transmissions

18-speed full power shift

Production years

2002-2006

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew Holland (a part of CNH)Reference

Row-Crop tractorReference

Built in Racine, Wisconsin, USAReference

Four-wheel driveReference

Differential lockelectro-hydraulicReference

Power steeringReference

Hydraulic wet disc brakesReference

Cab standard with air-conditioning.Reference

Variants

MX230similar CaseIH modelReference

Engine

CDC 8.3L 6-cyl dieselReference

Fuel tank492.1 LReference

Fuel tank605.6 LReference

Engine171.5 kWReference

Drawbar (tested)121.8 kWReference

CDCReference

turbocharged dieselReference

6-cylinder 12-valveReference

liquid-cooled inlineReference

Displacement8.3 LReference

Bore/Stroke114 x 135 mmReference

Power171.5 kWReference

Air cleanerdry two-stageReference

Compression18:1Reference

Rated RPM2200Reference

Idle RPM850-2485Reference

Firing order1-5-3-6-2-4Reference

Starter volts12Reference

Intake valve clearance0.254 mmReference

Exhaust valve clearance0.508 mmReference

Max power161.3 kWReference

Power at rated engine speed144.2 kWReference

Max power121.8 kWReference

Transmission

18-speed full power shiftReference

24-speed creeperReference

Typefull power shiftReference

Gears18 forward and 4 reverseReference

Clutchelectro-hydraulic wet discReference

TypecreeperReference

Gears24 forward and 6 reverseReference

PTO & Hydraulics

PTO (claimed)141.7 kWReference

PTO (tested)161.3 kWReference

Typeclosed center load sensingReference

Pressure202.0 barReference

Valves3 to 5Reference

Pump flow146.1 lpmReference

Pump flow257.4 lpmReference

Rear TypeIII/IIINReference

Controlposition and electronic draft controlReference

Rear lift (at 24"/610mm)6332 kgReference

Rear lift (at 24"/610mm)7243 kgReference

Rear lift (at 24"/610mm)6704 kgReference

Front HitchIIINReference

Front lift (at 24"/610mm)4166 kgReference

Front lift (at 24"/610mm)4286 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type1000 (1.75)Reference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@2000Reference

Engine RPM1000@2000Reference

Power at rated PTO speed159.3 kWReference

Dimensions

Wheelbase307 cmReference

Wheelbase328 cmReference

Weight19582 to 20382 poundsReference

Front tire16.9R30Reference

Rear tire20.8R42Reference

Standard tires (ag)Front: 16.9R30. Rear: 20.8R42Reference

Length518 cmReference

Height314 cmReference

Ground clearance42 cmReference

Front axle4WDReference

Front axleSuperSteerReference

Front axleTerraGlideReference

Shipping8882 kgReference

Shipping9245 kgReference

Shipping9060 kgReference

Operating9226 kgReference

Ballasted11478 kgReference

New Holland TG230 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps135Reference

Batteries2Reference

Battery CCA1000Reference

Battery volts12Reference

Battery Group31Reference

Test results

Diesel 18-speed 4WDSeptember 24 - October 27, 2003Link: OCED Tractor Test 1830 fileReference

PTO performanceReference

Fuel use46.2 l/hourReference

Fuel use48.4 l/hourReference

Drawbar performanceReference

Fuel use48.8 l/hourReference

Gear 7 used for power test.Reference

Max pull8993 kgReference

Gear 4 used for pull test.Reference

Speeds

With 20.8R42 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
