Tractor · 2014Unverified
New Holland TI4.65
New Holland TI4.65 — TI4 Series · 65 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Weight
3902 to 4079 pounds
Hover a source tag to verify
Overview
DistributorNew Holland (a part of CNH)Reference
ManufacturerGoldoniReference
Orchard/Vineyard tractorReference
Built in ItalyReference
Drive4x4 4WDReference
Final drivesmechanical front and rearReference
Hydraulic wet disc brakesReference
Two-post folding mid-mount ROPS.Reference
Engine
VM Motori 2.1L 3-cyl dieselReference
Fuel tank50.0 LReference
Engine (gross)48.6 kWReference
VM Motori D703Reference
turbocharged intercooled dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement2.1 LReference
Bore/Stroke94 x 100 mmReference
EmissionsStage 3AReference
Rated Power (gross)48.6 kWReference
Fuel systemdirect injectionReference
Rated RPM2600Reference
Starter typeelectricReference
Transmission
16-speedReference
12-speedReference
Gears16 forward and reverseReference
Clutch280mm dry discReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
Valves2Reference
Pump flow40.1 lpmReference
Rear TypeI/INReference
Rear lift1799 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540 (1.375)Reference
Dimensions
Weight3902 to 4079 poundsReference
Front tire280/70-18Reference
Rear tire280/70-18Reference
Standard tires (ag)Front: 280/70-18. Rear: 280/70-18Reference
Optional tires (ag)Front: 300/65-18. Rear: 300/65-18Reference
Length293 cmReference
Length310 cmReference
Width134 cmReference
Width116 cmReference
Ground clearance29 cmReference
Ground clearance27 cmReference
Front tread105 to 151 cmReference
Front tread88 to 128 cmReference
Rear tread105 to 151 cmReference
Rear tread88 to 128 cmReference
1789 kgReference
1769 kgReference
1850 kgReference
Steering wheel121 cmReference
Steering wheel118 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
New Holland TI4.65 Height
ROPS211 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
