Tractor · 2002Unverified
New Holland TJ275
New Holland TJ275 — TJ I Series · 239 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
239 hp
Max power
204.4 kW
Weight
14417 kg
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Four-wheel Drive (4WD) tractorReference
Built in Fargo, North Dakota, USAReference
The New Holland TJ275 is the same as the CaseIH STX275.Reference
Four-wheel driveReference
Final drivesinboard planetaryReference
Steeringhydrostatic powerReference
Integrated hydraulic wet disc brakesReference
Cab standardReference
Variants
STX275similar CaseIH modelReference
Engine
CDC 8.3L 6-cyl dieselReference
Fuel tank757.0 LReference
Engine205.1 kWReference
Drawbar (tested)157.8 kWReference
CDC 6TAA-8304Reference
turbocharged aftercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.3 LReference
Bore/Stroke114 x 135 mmReference
Power205.1 kWReference
Air cleanerdual paper elementsReference
Compression17.1:1Reference
Rated RPM2000Reference
Torque1385.8 NmReference
Starter volts12Reference
Oil capacity23.8 LReference
Coolant capacity43.2 LReference
Max power204.4 kWReference
Power at rated engine speed178.2 kWReference
Max power157.8 kWReference
Transmission
16-speed full power shiftReference
24-speedReference
Typefull power shiftReference
Gears16 forward and 2 reverseReference
Clutchelectro-hydraulic wet discReference
TransmissionsynchroshiftReference
Gears24 forward and 6 reverseReference
PTO & Hydraulics
PTO (claimed)167.8 kWReference
PTO (tested)204.4 kWReference
Typeclosed center load sensingReference
Rear valves4 to 7Reference
SCV flow132.5 lpmReference
Total flow151.4 lpmReference
Total flow208.2 lpmReference
Total flow283.9 lpmReference
Rear TypeIVN/IIIReference
Rear lift (at 24"/610mm)6577 kgReference
Rear PTOindependentReference
Rear PTO Type1000 (1.75)Reference
Dimensions
Wheelbase353 cmReference
Weight14417 kgReference
Front tire18.4R46Reference
Rear tire18.4R46Reference
Ag front18.4R46Reference
Ag rear18.4R46Reference
Length750 cmReference
Height368 cmReference
Operating weight14417 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps135Reference
Battery CCA1000Reference
Battery volts12Reference
Test results
Diesel 16-speed 4WDOctober 3 - 12, 2001Link: Nebraska Tractor Test 1796 fileReference
PTO performanceReference
Fuel use56.8 l/hourReference
Fuel use51.5 l/hourReference
Drawbar performanceReference
Fuel use51.9 l/hourReference
Gear 4 used for power test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
