Tractor · 2006Unverified
New Holland TJ280
New Holland TJ280 — TJ II Series · 280 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
280 hp
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Built in Fargo, North Dakota, USAReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Integral hydraulic wet disc brakesReference
Cab standard with heat and air-conditioningReference
Engine
CNH 8.3L 6-cyl dieselReference
Fuel tank757.0 LReference
Engine208.8 kWReference
CNHReference
turbocharged aftercooled dieselReference
6-cylinder 24-valveReference
liquid-cooledReference
Displacement8.3 LReference
Bore/Stroke114 x 135 mmReference
Power208.8 kWReference
Maximum Power229.7 kWReference
Rated RPM2000Reference
Torque1360.1 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts24Reference
Oil capacity24.0 LReference
Coolant capacity43.2 LReference
Transmission
16-speed full power shiftReference
24-speed full synchro shiftReference
Typefull power shiftReference
Gears16 forward and 2 reverseReference
Typefull synchro shiftReference
Gears24 forward and 6 reverseReference
PTO & Hydraulics
PTO (claimed)208.8 kWReference
Typeclosed center load sensing (CCLS)Reference
Pressure137.9 barReference
Valves4 to 9Reference
Pump flow124.9 lpmReference
Total flow151.4 lpmReference
Total flow208.2 lpmReference
Total flow340.7 lpmReference
Rear TypeIVN/III (optional)Reference
Rear lift (at 24"/610mm)7107 kgReference
Rear PTOindependentReference
Rear PTO Type1000 (optional)Reference
Dimensions
Wheelbase353 cmReference
Front tire20.8R42Reference
Rear tire20.8R42Reference
Ag front20.8R42Reference
Ag rear20.8R42Reference
Length701 cmReference
Height360 cmReference
Max weight17962 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps150Reference
Charging amps175 (optional)Reference
Batteries2Reference
Battery volts12Reference
Battery AH1000Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
