Tractor · 2006Unverified
New Holland TJ330
New Holland TJ330 — TJ II Series · 286 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
286 hp
Max power
241.1 kW
Weight
14569 kg
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Built in Fargo, North Dakota, USAReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Integral hydraulic wet disc brakesReference
Cab standard with heat and air-conditioningReference
Engine
CDC 8.9L 6-cyl dieselReference
Fuel tank757.0 LReference
Engine246.1 kWReference
Drawbar (tested)192.9 kWReference
CDCReference
turbocharged aftercooled dieselReference
6-cylinder 24-valveReference
liquid-cooledReference
Displacement8.9 LReference
Bore/Stroke114 x 145 mmReference
Power246.1 kWReference
Maximum Power270.7 kWReference
Compression16.6:1Reference
Rated RPM2000Reference
Torque1601.4 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts24Reference
Oil capacity27.7 LReference
Coolant capacity47.3 LReference
Max power241.1 kWReference
Power at rated engine speed213.1 kWReference
Max power192.9 kWReference
Transmission
16-speed full power shiftReference
24-speed full synchro shiftReference
Typefull power shiftReference
Gears16 forward and 2 reverseReference
Typefull synchro shiftReference
Gears24 forward and 6 reverseReference
PTO & Hydraulics
PTO (claimed)246.1 kWReference
PTO (tested)241.1 kWReference
Typeclosed center load sensing (CCLS)Reference
Pressure137.9 barReference
Valves4 to 9Reference
Pump flow124.9 lpmReference
Total flow151.4 lpmReference
Total flow208.2 lpmReference
Total flow340.7 lpmReference
Rear TypeIVN/III (optional)Reference
Rear lift (at 24"/610mm)7107 kgReference
Rear PTOindependentReference
Rear PTO Type1000 (optional)Reference
Dimensions
Wheelbase353 cmReference
Weight14569 kgReference
Front tire20.8R42Reference
Rear tire20.8R42Reference
Ag front20.8R42Reference
Ag rear20.8R42Reference
Length701 cmReference
Height360 cmReference
Operating weight14569 kgReference
Max weight17962 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps150Reference
Charging amps175 (optional)Reference
Batteries2Reference
Battery volts12Reference
Battery AH1000Reference
Test results
Diesel 16-speed 4WDSeptember 19 - October 22, 2007Link: OCED Tractor Test 1907A fileReference
PTO performanceReference
Fuel use68.1 l/hourReference
Fuel use64.3 l/hourReference
Drawbar performanceReference
Fuel use64.0 l/hourReference
Gear 5 used for power test.Reference
Max pull14150 kgReference
Gear 3 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
