Tractor · 2006Unverified
New Holland TJ480
New Holland TJ480 — TJ II Series · 429 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
429 hp
Max power
360.3 kW
Weight
20171 kg
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Built in Fargo, North Dakota, USAReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Integral hydraulic wet disc brakesReference
Cab standard with heat and air-conditioningReference
Engine
Cummins 14.9L 6-cyl dieselReference
Fuel tank1135.5 LReference
Engine357.9 kWReference
Drawbar (tested)291.7 kWReference
Cummins QSX15Reference
turbocharged aftercooled dieselReference
6-cylinder 24-valveReference
liquid-cooledReference
Displacement14.9 LReference
Bore/Stroke137 x 169 mmReference
Power357.9 kWReference
Maximum Power394.5 kWReference
Compression17.0:1Reference
Rated RPM2000Reference
Torque2417.7 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts24Reference
Oil capacity49.2 LReference
Coolant capacity79.9 LReference
Max power360.3 kWReference
Power at rated engine speed319.9 kWReference
Max power291.7 kWReference
Transmission
16-speed full power shiftReference
Typefull power shiftReference
Gears16 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)357.9 kWReference
PTO (tested)360.3 kWReference
Typeclosed center load sensing (CCLS)Reference
Pressure137.9 barReference
Valves4 to 9Reference
Pump flow124.9 lpmReference
Total flow151.4 lpmReference
Total flow208.2 lpmReference
Total flow340.7 lpmReference
Rear TypeIVN (optional)Reference
Rear lift (at 24"/610mm)8899 kgReference
Rear PTOindependentReference
Rear PTO Type1000 (optional)Reference
Dimensions
Wheelbase391 cmReference
Weight20171 kgReference
Front tire20.8R42Reference
Rear tire20.8R42Reference
Ag front20.8R42Reference
Ag rear20.8R42Reference
Length756 cmReference
Height381 cmReference
Operating weight20171 kgReference
Max weight24494 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps150Reference
Charging amps175 (optional)Reference
Batteries2Reference
Battery volts12Reference
Battery AH1000Reference
Test results
Diesel 16-speed 4WDSeptember 28 - October 24, 2007Link: OCED Tractor Test 1910A fileReference
PTO performanceReference
Fuel use101.8 l/hourReference
Fuel use95.8 l/hourReference
Drawbar performanceReference
Fuel use95.4 l/hourReference
Gear 4 used for power test.Reference
Max pull20240 kgReference
Gear 3 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
