Tractor · 2009Unverified

New Holland TK4020

Name: New Holland TK4020
Brand: New Holland

New Holland TK4020 — TK4000 Series · 64 hp. Reference specifications; pending source verification.

The New Holland TK4020 is a compact tractor model with a rated output of 64 hp. It was produced from 2009 to 2017 and features a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, coupled with an 8-speed gearbox and a tracked undercarriage. The tractor's weight ranges from 7209 to 7363 pounds. It is suitable for applications involving around 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

64 hp

Max power

64.4 hp

Weight

7209 to 7363 pounds

Catalogue coverage

Variants represented

Richest spec table

71 rows

Recorded power

64 hp

Recorded weight

3270 kg

Transmissions

8-speed

Production years

2009-2017

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Agricultural Crawler tractorReference

Built in Jesi, ItalyReference

DrivecrawlerReference

Two-post mid-mount folding ROPS.Reference

Variants

TK4020Fnarrow chassisReference

TK4020Vultra-narrow chassisReference

Engine

FPT 3.2L 4-cyl dieselReference

Fuel tank82.9 LReference

Engine (gross)48.0 kWReference

FPT F5CReference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.2 LReference

Bore/Stroke99 x 104 mmReference

EmissionsTier IIIReference

Rated Power (gross)48.0 kWReference

Rated RPM2300Reference

Torque290.0 NmReference

Torque RPM1300Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders4 CylinderReference

Rated engine speed2,300 RPMReference

Emissions complianceTier IIIReference

Engine torque at rated speed97 kgReference

Bore and stroke3.898x4.094 inchesReference

Cooling systemliquid-cooledReference

Transmission

8-speedReference

16-speed creeperReference

Gears8 forward and reverseReference

TypecreeperReference

Gears16 forward and 8 reverseReference

forward and reverse options8F and 8R | Creeper : 16F and 8 RReference

Wheel DriveTrackReference

Track Drive type4WDReference

PTO & Hydraulics

Typeopen centerReference

Pump flow35.6 lpmReference

Rear PTOindependentReference

Rear PTO Type540/540EReference

Dimensions

Weight7209 to 7363 poundsReference

9.8-inch tracksReference

Length317 cmReference

TK4020V Width115 cmReference

TK4020V Width130 cmReference

Height (steering wheel)98 cmReference

Height (ROPS)208 cmReference

TK4020V Weight3270 kgReference

TK4020F Weight3339 kgReference

TK4020V Gauge89 cmReference

TK4020F Gauge100 cmReference

Electrical

Charging systemalternatorReference

Battery volts12Reference

New Holland TK4020 Tracks

TK4020V width24 cmReference

TK4020F width29 cmReference

TK4020F width26 cmReference

TK4020F width30 cmReference

General

Make & ModelNew HollandReference

Rollover protective structureTwo-post mid-mount folding ROPSReference

Country of manufacturerItalyReference

Capacities

Capacity195 ciReference

Power

Max Power64.4 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Hydraulics

Hydraulics Typeopen centerReference

Dimensions & weight

Height Over ROPS208 cmReference

Overall Length317.2 cmReference

Overall Width130 cmReference

Overall weight3,339.8 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
