Tractor · 2009Unverified

New Holland TK4040

Name: New Holland TK4040
Brand: New Holland

New Holland TK4040 — TK4000 Series · 81 hp. Reference specifications; pending source verification.

The New Holland TK4040 is a tractor with a rated power output of 81 hp, falling within the mid-range for its class. Production of the TK4040 spanned the period from 2009 to 2017. Key features include a 4-cylinder turbocharged intercooled diesel liquid-cooled engine and a tracked undercarriage paired with an 8-speed gearbox. The TK4040's operating weight ranges from 8796 to 9524 pounds and it is suited to operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

81 hp

Max power

81.2 hp

Weight

8796 to 9524 pounds

Catalogue coverage

Variants represented

Richest spec table

76 rows

Recorded power

81 hp

Transmissions

8-speed

Production years

2009-2017

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerNew HollandReference

Agricultural Crawler tractorReference

Built in Jesi, ItalyReference

DrivecrawlerReference

Two-post mid-mount folding ROPS. Cab available.Reference

Variants

TK4040standard chassisReference

TK4040Mwide chassisReference

Engine

FPT 3.2L 4-cyl dieselReference

Fuel tank110.9 LReference

Engine (gross)60.6 kWReference

FPT F5CReference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.2 LReference

Bore/Stroke99 x 104 mmReference

EmissionsTier IIIReference

Rated Power (gross)60.6 kWReference

Rated RPM2300Reference

Torque352.0 NmReference

Torque RPM1300Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders4 CylinderReference

Rated engine speed2,300 RPMReference

Emissions complianceTier IIIReference

Engine torque at rated speed117.8 kgReference

Bore and stroke3.898x4.094 inchesReference

Cooling systemliquid-cooledReference

Transmission

8-speedReference

16-speed creeperReference

Gears8 forward and reverseReference

TypecreeperReference

Gears16 forward and 8 reverseReference

forward and reverse options8F and 8R | Creeper : 16F and 8 RReference

Wheel DriveTrackReference

Track Drive type4WDReference

PTO & Hydraulics

Typeopen centerReference

Pump flow41.3 lpmReference

Rear PTOindependentReference

Rear PTO Type540/540EReference

Dimensions

Weight8796 to 9524 poundsReference

13.8-inch tracksReference

Length325 cmReference

Width140 cmReference

TK4040M Width169 cmReference

Gauge109 cmReference

TK4040M Gauge130 cmReference

TK4040 ROPS3989 kgReference

TK4040M ROPS4120 kgReference

TK4040 Cab4189 kgReference

TK4040M Cab4320 kgReference

Steering wheel103 cmReference

Electrical

Charging systemalternatorReference

Battery volts12Reference

New Holland TK4040 Tracks

Width35 cmReference

TK4040 width30 cmReference

TK4040M width40 cmReference

New Holland TK4040 Height

ROPS234 cmReference

Cab194 cmReference

General

Make & ModelNew HollandReference

Rollover protective structureTwo-post mid-mount folding ROPSReference

Country of manufacturerItalyReference

Capacities

Capacity195 ciReference

Power

Max Power81.2 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Hydraulics

Hydraulics Typeopen centerReference

Dimensions & weight

Height Over Cab194.3 cmReference

Height Over ROPS235 cmReference

Overall Length325.1 cmReference

Overall Width169.9 cmReference

Overall weight3,989.8 kgReference

Track width35.1 cmReference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
